The product may differ from the illustration
Festo pneumatic cylinder for precise linear motion and defined force in automation.
Mini Slide EGSC-BS-KF-25-75-6P - Festo 8061280
FESTO
Original product
Net price (excl. VAT)
€574.40
Excl. 19% VAT ,
excl. Shipping Cost
Item
FES-8061280
Manufacturer no.
EGSC-BS-KF-25-75-6P
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.EGSC-BS-KF-25-75-6P
EAN4052568295653
Customs tariff number84799070
ConditionNew
Article
FES-8061280
Frequently Bought Together
-
This Item:
€574.40Excl. 19% VAT , excl. Shipping Cost
-
Electric Cylinder ESBF-BS-63-100-5P - Festo 574093
€1,862.42Excl. 19% VAT , excl. Shipping Cost
-
Electric Slide EGSK-33-200-10P - Festo 562779
€1,263.44Excl. 19% VAT , excl. Shipping Cost
Total price
Festo pneumatic cylinder for precise linear motion and defined force in automation. The key technical data of this genuine Festo article are listed below.
| Working stroke [mm] | 75 |
| size | 25 |
| Stroke reserve [mm] | 0 |
| Reversing play [µm] | 150 |
| Spindle diameter [mm] | 6 |
| Spindle pitch [mm/U] | 6 |
| installation position | arbitrary |
| Guide | ball guide |
| Construction set up | Electrical mini-carriages<br>with ball screw drive |
| Motor type | Step motor<br>Servo motor |
| Referencing | Fixed stopper block negative<br>Fixed stopper block positive<br>Reference switch |
| Spindle type | Ball screw drive |
| Position detection | For proximity switch |
| Max. acceleration [m/s²] | 15 |
| Max. speed [m/s] | 0,4 |
| Repeatability | ±0.015 mm |
| Power-on time | 100 % |
| Corrosion resistant class KBK | 0 - No corrosion stressing |
| Sound level [dB(A)] | 50 |
| Protection category | IP40 |
| ambient temperature [°C] | 0 to 50 |
| Dynamic load factor fixed bearing [N] | 2.810 |
| Dynamic load factor linear guide [N] | 1.310 |
| Dynamic load factor ball screw drive [N] | 1.700 |
| Max. force Fy [N] | 669 |
| Max. force Fz [N] | 669 |
| Max. torque Mx [Nm] | 2,00 |
| Max. torque My [Nm] | 2,11 |
| Max. torque Mz [Nm] | 2,11 |
| Max. radial force on drive shaft [N] | 50 |
| Max. feed force Fx [N] | 20 |
| Guideline payload, horizontal [KGM] | 1 |
| Guideline payload, vertical [KGM] | 1 |
| Static load factor ball screw drive [N] | 2.600 |
| Static load factor linear guide [N] | 2.440 |
| Mass inertia JH per metre stroke [kg/cm²] | 0,01507 |
| Mass inertia JL per kg usable load [kg/cm²] | 0,00912 |
| Mass inertia JO [kg/cm²] | 0,00144 |
| Feed constant [mm/U] | 6 |
| Static load factor fixed bearing [N] | 1.340 |
| Guideline running performance [km] | 5.000 |
| Maintenance interval | Lifetime lubrication |
| Moving mass at 0 mm stroke [g] | 83 |
| Weight supplement per 10 mm stroke [g] | 19 |
| Base weight at 0 mm stroke [g] | 176 |
| Product weight [g] | 315 |
| Supplement moved mass per 10 mm stroke [g] | 9 |
| Fastening type | with female threads<br>with centring sleeve<br>with accessories<br>with cylinder pin |
| Interface code actuator | V20 |
| Material information | LABS containing materials included<br>RoHs compliant |
| Carriage guide material | Roller bearing steel |
| Guide carriage material | Roller bearing steel |
| Housing material | Aluminium wrought alloy, anodised |
| Joch plate material | Aluminium wrought alloy, anodised |
| Piston rod material | High-alloyed stainless steels |
| Carriage material | Aluminium wrought alloy, anodised |
| Spindle nut material | Roller bearing steel |
| Spindle material | Roller bearing steel |
| Manufacturer Nr. | EGSC-BS-KF-25-75-6P |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568295653 |
| Weight | 0.315000 |
| HS-Code | 84799070 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Werkstoff | Aluminium |
| Schutzart | IP40 |
