Images are for illustration purposes only and may differ from the actual product. Some images have been generated or edited, in whole or in part, using artificial intelligence systems. The technical specifications in the product description are authoritative.
The RMSE-2QG is an ESD-safe complete rework system that combines soldering, electric desoldering and hot air in stackable modules. With a T245 iron, DR560 desoldering iron, MSE pump and a 700 W hot air station, it covers PCB repair and assembly work at a single bench.
ESD Rework System with Soldering, Electric Desoldering and 700 W Hot Air, 230 V - JBC RMSE-2QG
JBC
Original product
Net price (excl. VAT)
€4,448.16
Item
WL86781
Manufacturer no.
RMSE-2QG
ESD · IEC 61340-5-1
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.RMSE-2QG
EAN8427327569898
Country of originSpain
Customs tariff number85151100
ConditionNew
Article
WL86781
Frequently Bought Together
-
This Item:
€4,448.16
-
SMD Rework System with Hot Air, Preheater and Rework Arm, 230 V - JBC SRWS-2SC
€4,918.10
-
Precision hot air station 300 W 150-450 °C without extractor desk - JBC TESE-2QB
€1,871.75
Total price
The JBC RMSE-2QG brings together every tool a rework bench needs for soldering, desoldering and hot air work on printed circuit boards. The soldering iron, electric desoldering iron with vacuum pump and power hot air station run at the same time and share a compact, stackable layout.
Benefits
- DDE-2C control unit drives two tools simultaneously with up to 150 W per tool.
- T245-A soldering iron with the efficient JBC heating system for fast warm-up and stable tip temperature (±1.5 °C at idle).
- DR560-A desoldering iron with the electric MSE-B pump for clean, continuous solder removal without compressed air.
- JTSE-2B hot air station rated at 700 W for SMD components and larger joints.
- Sleep and Hibernation modes extend tip life and cut energy use.
Technical data
- Hot air power: 700 W
- Power per soldering/desoldering tool: up to 150 W
- Temperature range: 90-450 °C (190-840 °F)
- Supply voltage: 230 V
- Tip to ground resistance: < 2 ohm
- Tip to ground voltage: < 2 mV RMS
- Dimensions: 700 x 410 x 390 mm
- Net weight: 14.83 kg
Applications
Suited to repair, rework and small-batch assembly in electronics production, labs and service, covering both SMD and through-hole components.
What is in the box
- DDE-2C 2-tool control unit
- JTSE-2B power hot air station
- MSE-B electric desoldering module
- T245-A soldering iron
- DR560-A desoldering iron
- AD-SF and DR-SF stands
- Instruction manual
Soldering tips (C245 series) and desoldering nozzles (C560 series) are not included and are ordered separately.
Standards
ESD-safe to IEC 61340-5-1, CE, RoHS. Made in Spain.
| Certification | IEC 61340-5-1 |
|---|---|
| ESD version | ESD (antistatic) |
| Manufacturer Nr. | RMSE-2QG |
| Manufacturer | JBC |
| Country of Manufacture | Spain |
| EAN | 8427327569898 |
| Weight | 14.830000 |
| HS-Code | 85151100 |
| GPSR manufacturer information | JBC Soldering SL, Ramón y Cajal 3, ES-08750 Molins De Rei, www.jbctools.com |
| Article authenticity | Original product |
| Condition of article | New |
| Power | 150 W |
| Temperature range | 90-450 °C |
| Temperature (max.) | up to 450 °C |
| Position sensing | No |
