Conductive PUR foam in soft grade, sheet size 553 x 353 mm at 6 mm material thickness. At 10E3 to 10E4 ohm the foam drains charge directly and component leads can be pushed straight in. Intended as an insert in ESD containers and cartons.
ESD Foam PUR EL23 Conductive, 553 x 353 mm, 6 mm Thick - A1-ESD EP0705135
A1-ESD
Original product
Net price (excl. VAT)
€2.20
Item
EP0705135
Manufacturer no.
EP0705135
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.EP0705135
ConditionNew
Article
EP0705135
Frequently Bought Together
-
This Item:
€2.20
-
Schaumstoffstäbchen 164 mm
€18.95
-
Schaumstoffstäbchen 163 mm
€19.34
Total price
Leaded parts and sensitive assemblies need an insert that gives way and drains charge at once. PUR foam EL23 is a soft grade and sits at 10E3 to 10E4 ohm in the conductive range, sheet size 553 x 353 mm at 6 mm material thickness.
Benefits
- Conductive at 10E3 to 10E4 ohm, the low resistance drains charge directly.
- Soft grade, component leads can be pushed in without bending them.
- Sheet size 553 x 353 mm, covers large container floors and can be split into smaller compartment formats.
- Material thickness 6 mm, it sets the insertion depth for leads and the remaining cushioning travel.
- Black throughout, conductive material stays distinguishable from dissipative packaging foam.
- Polyurethane base, the material is light and adds little to the shipping weight.
Technical data
| Article number | EP0705135 |
|---|---|
| Manufacturer | A1-ESD |
| Type | PUR foam EL23 |
| Colour | black |
| Sheet size | 553 x 353 mm |
| Material thickness | 6 mm |
| Resistance | 10E3 to 10E4 ohm |
| Classification | conductive |
| Grade | soft |
| Weight | 0.1 kg |
| eCl@ss | 14070604 |
| UNSPSC | 24125000 |
Application
Typical uses are inserting leaded components and connectors, lining ESD containers and cartons, and cushioning assemblies that move between production, test area and store.
About the range
The 553 x 353 mm sheet is also available in 10 mm and 15 mm within the range. This article is the 6 mm version.
| Manufacturer Nr. | EP0705135 |
|---|---|
| Manufacturer | A1-ESD |
| Weight | 0.100000 |
| GPSR manufacturer information | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
