Festo ADN-16-30-A-P-A (536224) Compact Cylinder

Festo
€3,904.00
Excl. 19% VAT , excl. Shipping Cost
Article
FES-536224

Manufacturer Nr.
ADN-16-30-A-P-A
Compact Cylinder
Add to Wish List Add to Compare
main product photo
The product may differ from the illustration
Frequently Bought Together
Total price
Stroke [mm] 30
Piston diameter 16 mm
Piston rod thread M6
Dampening P: Elastic silencer rings / plates double-sided
installation position arbitrary
Complies to standard ISO 21287
Piston rod end Male thread
Position detection For proximity switch
Variants One-sided piston rod
Operating pressure [bar] 1 to 10
Principle of operation double acting
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium Oiled operation possible (required in further operations)
Corrosion resistant class KBK 2 - moderate corrosion stress
ambient temperature [°C] -20 to 80
Impact energy at the end positions [J] 0,15
Theoretical force at 6 bar, Return flow [N] 90
Theoretical force at 6 bar, flow [N] 121
Moving mass at 0 mm stroke [g] 15
Weight supplement per 10 mm stroke [g] 14
Base weight at 0 mm stroke [g] 79
Supplement moved mass per 10 mm stroke [g] 4
Fastening type With throughway bores
With female thread
With Accessories
Selectively:
Pneumatic connection M5
Material information RoHs compliant
Cover material aluminium
anodized
Seals material TPE-U(PUR)
Piston rod material High-alloyed steel
Cylinder tube material Aluminium wrought alloy
Smooth anodised
More Information
Manufacturer Nr. ADN-16-30-A-P-A
Manufacturer Festo
EAN 4052568087302
Weight 0.115000
HS-Code 84123100
GPSR manufacturer information Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity Original product
Condition of article New
