Festo pneumatic cylinder for precise linear motion and defined force in automation.
Short-Stroke Cylinder AEVC-16-10-I-P - Festo 188100
FESTO
Original product
Net price (excl. VAT)
€53.44
Excl. 19% VAT ,
excl. Shipping Cost
Available
Fast shipping
Item
FES-188100
Manufacturer no.
AEVC-16-10-I-P
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.AEVC-16-10-I-P
EAN4052568076887
Customs tariff number84123100
ConditionNew
Article
FES-188100
Frequently Bought Together
-
This Item:
€53.44Excl. 19% VAT , excl. Shipping Cost
-
Short-Stroke Cylinder ADVC-20-15-I-P - Festo 188147
€58.52Excl. 19% VAT , excl. Shipping Cost
-
Short-Stroke Cylinder AEVC-16-25-I-P - Festo 188101
€55.49Excl. 19% VAT , excl. Shipping Cost
Total price
Festo pneumatic cylinder for precise linear motion and defined force in automation. The key technical data of this genuine Festo article are listed below.
| Stroke [mm] | 10,0 |
| Piston diameter | 16 mm |
| Spring return force for retracted piston rod [N] | 5 |
| Dampening | P: Elastic silencer rings / plates double-sided |
| installation position | arbitrary |
| Principle of operation | Pressing<br>single action |
| Construction set up | Piston<br>piston rod |
| Position detection | without |
| Operating pressure [bar] | 1.5 to 10 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 1 - low corrosion stress |
| ambient temperature [°C] | -20 to 80 |
| Theoretical force at 6 bar, flow [N] | 112,0 |
| Moving mass [g] | 11,00 |
| Product weight [g] | 80,0 |
| Fastening type | With throughway bores<br>With Accessories<br>Selectively: |
| Pneumatic connection | M5 |
| Material information | Copper and PTFE-free |
| Cover material | Aluminium wrought alloy<br>anodized |
| Seals material | NBR<br>TPE-U(PU) |
| Housing material | Aluminium wrought alloy<br>anodized |
| Piston rod material | High-alloyed steel |
| Manufacturer Nr. | AEVC-16-10-I-P |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568076887 |
| Weight | 0.080000 |
| HS-Code | 84123100 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Werkstoff | Aluminium |
| Bohrung (mm) | 16.000000 |
| Betriebsdruck max [bar] | 10.000000 |
| Hub [mm] | 10.000000 |
| Pneumatischer Anschluss | M5 |
