Festo AEVC-4-5-A-P (188053) Short-Stroke Cylinder

Name: Festo AEVC-4-5-A-P (188053) Short-Stroke Cylinder
Brand: Festo
SKU: FES-188053
Price: 3442 EUR
Availability: InStock

€3,442.00

Excl. 19% VAT , excl. Shipping Cost

Article

FES-188053

Manufacturer Nr.

AEVC-4-5-A-P

Short-Stroke Cylinder

The product may differ from the illustration

Frequently Bought Together

This Item: Festo AEVC-4-5-A-P (188053) Short-Stroke Cylinder
€3,442.00
Excl. 19% VAT , excl. Shipping Cost
Festo ADVC-20-20-I-P-A (188143) Short-Stroke Cylinder
€5,117.00
Excl. 19% VAT , excl. Shipping Cost
Festo AEVC-100-25-I-P-A (188325) Short-Stroke Cylinder
€24,206.00
Excl. 19% VAT , excl. Shipping Cost

Total price

Stroke [mm]	5,0
Piston diameter	4 mm
Spring return force for retracted piston rod [N]	1
Dampening	P: Elastic silencer rings / plates double-sided
installation position	arbitrary
Principle of operation	Pressing single action
Construction set up	Piston piston rod
Position detection	without
Operating pressure [bar]	2.5 to 8
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium	Oiled operation possible (required in further operations)
Corrosion resistant class KBK	1 - low corrosion stress
ambient temperature [°C]	-20 to 80
Theoretical force at 6 bar, flow [N]	4,9
Moving mass [g]	0,20
Product weight [g]	4,5
Fastening type	With throughway bores With Accessories Selectively:
Pneumatic connection	M3
Material information	Copper and PTFE-free
Cover material	Aluminium wrought alloy anodized
Seals material	HNBR NBR
Housing material	Aluminium wrought alloy anodized
Piston rod material	Aluminium wrought alloy anodized

More Information
Manufacturer Nr.	AEVC-4-5-A-P
Manufacturer	Festo
EAN	4052568076412
Weight	0.004400
HS-Code	84123100
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity	Original product
Condition of article	New
