Input/Output Module CPX-2ZE2DA - Festo 576046
FESTO
Original product
Net price (excl. VAT)
€475.67
Item
FES-576046
Manufacturer no.
CPX-2ZE2DA
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.CPX-2ZE2DA
EAN4052568261795
Customs tariff number85389099
ConditionNew
Article
FES-576046
Frequently Bought Together
-
This Item:
€475.67
-
Hood VMPA-KMS-H - Festo 533198
€27.04
-
Electrical Interface VMPA-ASI-EPL-EU-8E8A-Z - Festo 546994
€297.69
Total price
Festo pneumatic component for industrial automation and compressed-air applications in proven quality. The key technical data of this genuine Festo article are listed below.
| Dimensions W x L x H | 50 mm x 107 mm x 50 mm<br>(Incl. linking block and connectors) |
| Diagnosis | betriebsartenabhängige Diagnose |
| Parameterising | Input / output switching delay<br>Frequency output<br>Speed measurement<br>Impulse output<br>Impulse chain<br>Measure speed<br>Measure frequency<br>Measure period duration<br>Motor operating type<br>Position determination<br>Pulse width modulation<br>Numbers One-time<br>Numbers Endless<br>Numbers Periodic |
| LED displays | 1 Sammeldiagnose<br>10 Kanalstatus<br>2 Kanaldiagnose<br>2 Moduldiagnose |
| Operating voltage range DC [V] | 18 to 30 |
| Intrinsic power input at operating voltage | Type 35 mA |
| Max. power supply per channel | 5 A adjustable (20 W lamp test) |
| Nominal operating voltage DC [V] | 24 |
| Potential separation channel - internal bus | Outputs - yes, when using intermediate power supply |
| Potential separation channel - channel | no |
| Corrosion resistant class KBK | (In integrated condition)<br>1 - low corrosion stress |
| Bearing temperature [°C] | -20 to 70 |
| Protection category | IP65<br>IP67 |
| ambient temperature [°C] | -5 to 50 |
| Product weight [g] | 130,0 |
| Max. line length | 30 m |
| Material information | RoHs compliant |
| Housing material | Plastic |
| Quantity inputs | 2 |
| Input debouncing time | 0.1 µs (0.2µs,0.4µs,0.8µs,1µs,2µs,4µs,8µs,10µs,50µs,100µs,500µs,1ms,3ms,10ms,20ms parameterisable) |
| Fuse (short circuit) | Internal electronic fuse Per channel |
| Max. cumulative current inputs per module [A] | 2,0 |
| Switch level | Signal 0: <= 5 V<br>Signal 1: >= 11 V |
| Characteristic curves inputs | to IEC 1131-2 type 02 |
| Switching logic inputs | PNP (Positive switching) |
| Quantity outputs: | 2 |
| Max. cumulative current outputs per module [A] | 10,0 |
| Characteristic curves outputs | IEC1131-T2 |
| Switching logic outputs | PNP (Positive switching)<br>NPN (minus-switching)<br>Push-pull driver |
| Permission | UL - recognised (OL) |
| Pitch dimension [mm] | 50 |
| Norm | IEC 1131, IEC 1131-2 |
|---|---|
| Manufacturer Nr. | CPX-2ZE2DA |
| Manufacturer | Festo |
| EAN | 4052568261795 |
| Weight | 0.150000 |
| HS-Code | 85389099 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 50 |
| Material | Plastic |
| Protection rating | IP65 |
| Series | CPX |
| Operating voltage | 24 V DC |
| Corrosion resistance class CRC | 1 - low corrosion stress |
| Position sensing | No |
