Encoder Cable NEBM-REG6-E-7.5-Q14N-REG6 - Festo 5219215
Festo fitting or line component for fast, leak-tight and pressure-resistant compressed-air connections.
Net
excl. VAT
€65.83
Item
FES-5219215
Manufacturer no.
NEBM-REG6-E-7.5-Q14N-REG6
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Festo fitting or line component for fast, leak-tight and pressure-resistant compressed-air connections. The key technical data of this genuine Festo article are listed below.
Technical data
| Line designation | Without sign holder |
|---|---|
| Electrical connection 1, function | Field device screen |
| Electrical connection 1, design | Angular |
| Electrical connection 1, connection type | socket / container / …. |
| Electrical connection 1, cable output | straight |
| Electrical connection 1, connection technology | Anschlussbild RE |
| Electrical connection 1, number of pins / wires | 6 |
| Electrical connection 1, occupied pin / wire | 6 |
| Electrical connection 2, function | Control screen |
| Electrical connection 2, connection type | Plug |
| Electrical connection 2, connection technology | Anschlussbild RE |
| Electrical connection 2, number of pins / wires | 6 |
| Electrical connection 2, occupied pin / wire | 6 |
| Operating voltage range DC [V] | 0 to 30 |
| Cable length [MTR] | 7,50 |
| Line properties | Cable track capable |
| Bending radius, moving cable placement [mm] | >= 100 mm |
| Cable diameter [mm] | 8,3 |
| Cable set up | 2x0,51+4x0,205 |
| Conductor - nominal cross-section [mm²] | 0,205<br>0,51 |
| Protection category | IP20 |
| Information about protection category | In mounted condition |
| ambient temperature [°C] | -40 to 80 |
| Ambient temperature for moving cable placements [°C] | -10 to 80 |
| CE certificate (see declaration of conformity) | nach EU-RoHS-RL |
| Material information | LABS containing materials included<br>RoHs compliant |
| Cable sleeve material | PVC |
| Cable shield colour | <span class="farbe" style="background-color:#000000"></span> black |
| Corrosion resistant class KBK | 0 - No corrosion stressing |
| Insulation sleeve material | PVC |
| Operating voltage range AC [V] | 0 to 30 |
| Electrical connection 2, design | Angular |
| Electrical connection 2, cable output | straight |
| Degree of contamination | 3 |
| Current carrying capacity at 40°C [A] | 1,6 |
| Surge voltage strength [kV] | 2,00 |
| Bending radius, permanent cable placement [mm] | >= 83 mm |
| Test conditions line | Test conditions on request |
| Housing material | PVC |
| Housing colour | <span class="farbe" style="background-color:#C6C6C6"></span> Grey |
| Conductor nominal cross-section (AWG) | AWG20<br>AWG24 |
| Weight | 0.1 kg |
| Manufacturer | Festo |
| Manufacturer Nr. | NEBM-REG6-E-7.5-Q14N-REG6 |
| EAN | 4052568421182 |
| HS-Code | 85444290 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Condition of article | New |
| Article authenticity | Original product |
| Material | PVC |
| Corrosion resistance class CRC | 0 - No corrosion stressing |
| Series | NEBM |
| Protection class (IP) | IP20 |
| Temperature (max.) | 80 |
