Festo SPAN-V1R-G18M-PN-PN-L1 (8035546) Pressure Sensor
€9,316.00
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-8035546
Manufacturer Nr.
SPAN-V1R-G18M-PN-PN-L1
Pressure Sensor
Frequently Bought Together
-
This Item:
€9,316.00Excl. 19% VAT , excl. Shipping Cost
-
Festo SPAN-B2R-R18M-PN-PN-L1 (8035548) Pressure Sensor
€9,316.00Excl. 19% VAT , excl. Shipping Cost
-
Festo PEV-1/4-A-SW27 (159259) Pressure Switch
€10,294.00Excl. 19% VAT , excl. Shipping Cost
Total price
| Permission | RCM mark c UL us - Listed (OL) |
| CE certificate (see declaration of conformity) | acc. to EU-EMV Directive acc. to EU-RoHS Directive |
| KC-mark | KC-EMV |
| Certified awarding point | UL E322346 |
| Material information | RoHs compliant |
| Measured parameter | Relative pressure |
| Measurement process | Piezoresistive pressure sensor |
| Druckmessbereich Anfangswert (MPa) [MPa] | 0 |
| Pressure measurement range starting value [bar] | 0 |
| Druckmessbereich Anfangswert (psi) [psi] | 0 |
| Druckmessbereich Endwert (MPa) [MPa] | -0,1 |
| Pressure measurement range end value [bar] | -1 |
| Druckmessbereich Endwert (psi) [psi] | -14,5 |
| Overload range [bar] | 5 |
| Overload pressure [MPa] | 0,5 |
| Überlastdruck (psi) [psi] | 72,5 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] Inert gases |
| Information about operating and control medium | Oiled operation possible |
| Medium temperature [°C] | 0 to 50 |
| ambient temperature [°C] | 0 to 50 |
| Accuracy FS [%FS] | 1,5 |
| Repeatability in ± %FS [%FS] | 0,3 |
| Temperature coefficient in ± %FS/K [%FS/K] | 0,05 |
| Control output | 2 x PNP or 2 x NPN switchable |
| Switch function | Window comparator Threshold comparator Auto difference monitoring |
| Switching element function | Opener/closer switchable |
| Max. output current [mA] | 100 |
| Short circuit resistance | yes |
| Operating voltage range DC [V] | 15 to 30 |
| Reverse polarity protection | for all electrical connections |
| Electrical connection 1, connection type | Plug |
| Electrical connection 1, connection technology | Wiring diagram L1J |
| Electrical connection 1, number of pins / wires | 4 |
| Fastening type | Front panel integration With Wall / flat holder With thread |
| installation position | arbitrary |
| Pneumatic connection | Male thread G1/8 female thread M5 |
| Product weight [g] | 46 |
| Housing material | PA reinforced |
| From medium contacting materials | FPM NBR PA-verstärkt Messing, vernickelt |
| Display type | Illuminating LCD |
| Presentable unit(s) | MPa bar inchH2O inchHg kPa kgf/cm² mbar mmHg psi |
| Setting options | Teach-in Via display and buttons |
| Tamper-proof fuse | PIN code |
| Settings range threshold value [%] | 0 to 100 |
| Settings range hysteresis [%] | 0 to 90 |
| Protection category | IP40 |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| Manufacturer Nr. | SPAN-V1R-G18M-PN-PN-L1 |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568284862 |
| Weight | 0.070000 |
| HS-Code | 90262020 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
