Festo DSBC-50-200-PPSA-N3 (1376310) Standards-Based Cyli
€173.57
Excl. 19% VAT , excl. Shipping Cost
Article
FES-1376310
Manufacturer Nr.
DSBC-50-200-PPSA-N3
Standards-Based Cyli
Frequently Bought Together
- This Item: €173.57Excl. 19% VAT , excl. Shipping Cost
- Festo DSBC-50-60-D3-PPVA-N3 (3659472) Standards-Based Cyli €182.96Excl. 19% VAT , excl. Shipping Cost
- Festo DSBC-80-500-PPSA-N3 (1383377) Standards-Based Cyli €319.13Excl. 19% VAT , excl. Shipping Cost
Total price
| Stroke [mm] | 200 |
| Piston diameter | 50 mm |
| Piston rod thread | M16x1,5 |
| Dampening | PPS: Self-setting pneumatic end position dampening |
| installation position | arbitrary |
| Complies to standard | ISO 15552 |
| Piston rod end | Male thread |
| Construction set up | Piston piston rod profile tube |
| Position detection | For proximity switch |
| Variants | One-sided piston rod |
| Operating pressure [bar] | 0.4 to 12 |
| Principle of operation | double acting |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| ambient temperature [°C] | -20 to 80 |
| Impact energy at the end positions [J] | 1,0 |
| Dampening length [mm] | 22 |
| Theoretical force at 6 bar, Return flow [N] | 990 |
| Theoretical force at 6 bar, flow [N] | 1.178 |
| Moving mass at 0 mm stroke [g] | 365 |
| Weight supplement per 10 mm stroke [g] | 56 |
| Base weight at 0 mm stroke [g] | 1.190 |
| Supplement moved mass per 10 mm stroke [g] | 25 |
| Fastening type | With female thread With Accessories Selectively: |
| Pneumatic connection | G1/4 |
| Material information | RoHs compliant |
| Cover material | Alu-Druckguss, beschichtet |
| Werkstoff Kolbendichtung | TPE-U(PU) |
| Piston material | Aluminium wrought alloy |
| Piston rod material | High-alloyed steel |
| Werkstoff Kolbenstangen-Dichtabstreifer | TPE-U(PU) |
| Werkstoff Pufferdichtung | TPE-U(PU) |
| Werkstoff Pufferkolben | POM |
| Cylinder tube material | Aluminium-Knetlegierung, gleiteloxiert |
| Nut material | Zinc plated steel |
| Bearing material | POM |
| Flush screw material | Zinc plated steel |
| Manufacturer Nr. | DSBC-50-200-PPSA-N3 |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568231620 |
| Weight | 2.300000 |
| HS-Code | 84123100 |
