Festo DSBC-50-320-PPSA-N3 (1376312) Standards-Based Cyli

Festo
€13,566.00
Excl. 19% VAT , excl. Shipping Cost
Article
FES-1376312

Manufacturer Nr.
DSBC-50-320-PPSA-N3
Standards-Based Cyli
Add to Wish List Add to Compare
main product photo
The product may differ from the illustration
Frequently Bought Together
Total price
Stroke [mm] 320
Piston diameter 50 mm
Piston rod thread M16x1,5
Dampening PPS: Self-setting pneumatic end position dampening
installation position arbitrary
Complies to standard ISO 15552
Piston rod end Male thread
Construction set up Piston
piston rod
profile tube
Position detection For proximity switch
Variants One-sided piston rod
Operating pressure [bar] 0.4 to 12
Principle of operation double acting
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium Oiled operation possible (required in further operations)
Corrosion resistant class KBK 2 - moderate corrosion stress
ambient temperature [°C] -20 to 80
Impact energy at the end positions [J] 1,0
Dampening length [mm] 22
Theoretical force at 6 bar, Return flow [N] 990
Theoretical force at 6 bar, flow [N] 1.178
Moving mass at 0 mm stroke [g] 365
Weight supplement per 10 mm stroke [g] 56
Base weight at 0 mm stroke [g] 1.190
Supplement moved mass per 10 mm stroke [g] 25
Fastening type With female thread
With Accessories
Selectively:
Pneumatic connection G1/4
Material information RoHs compliant
Cover material Alu-Druckguss, beschichtet
Werkstoff Kolbendichtung TPE-U(PU)
Piston material Aluminium wrought alloy
Piston rod material High-alloyed steel
Werkstoff Kolbenstangen-Dichtabstreifer TPE-U(PU)
Werkstoff Pufferdichtung TPE-U(PU)
Werkstoff Pufferkolben POM
Cylinder tube material Aluminium-Knetlegierung, gleiteloxiert
Nut material Zinc plated steel
Bearing material POM
Flush screw material Zinc plated steel
More Information
Manufacturer Nr. DSBC-50-320-PPSA-N3
Manufacturer Festo
EAN 4052568231644
Weight 3.000000
HS-Code 84123100
GPSR manufacturer information Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity Original product
Condition of article New
