Festo sensor for reliable monitoring of position, pressure or status in the pneumatic system.
Pressure Switch PEV-1/4-B-M12 - Festo 192488
FESTO Original product
Net price (excl. VAT)
€134.09
Item FES-192488
Manufacturer no. PEV-1/4-B-M12
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.PEV-1/4-B-M12
EAN4052568007966
Customs tariff number85365080
ConditionNew
Article
FES-192488
Frequently Bought Together
- This Item: €134.09
- Pressure Sensor SPAW-P25R-G14F-2P-M12 - Festo 8022746 €251.22
- Pressure Sensor SPAN-V1R-G18M-PNLK-PNVBA-L1 - Festo 8035535 €109.08
Total price
Festo sensor for reliable monitoring of position, pressure or status in the pneumatic system. The key technical data of this genuine Festo article are listed below.
| Complies to standard | EN 60947-5-1 |
| Permission | CCC<br>c UL us - Recognized (OL) |
| CE certificate (see declaration of conformity) | to EU low voltage directive |
| Material information | RoHs compliant |
| Measured parameter | Relative pressure |
| Measurement process | Pneumatic electric pressure converter |
| Betriebsdruck Mpa [MPa] | 0,1 bis 1,2 |
| Operating pressure [bar] | 1 to 12 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-]<br>Water |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Medium temperature [°C] | -20 to 80 |
| ambient temperature [°C] | -20 to 80 |
| Switching element function | changeover contact |
| Max. switching frequency [Hz] | 3 |
| Max. switch off voltage AC [V] | 48 |
| Max. switch off voltage DC [V] | 48 |
| Max. output current [mA] | 4.000 |
| Minimum load current | 1 mA at 24 V<br>10 mA at 10 V<br>100 mA at 5V |
| Use category inductive load | AC-14<br>DC-13 |
| Use category ohmic load | AC-12<br>DC-12 |
| Electrical connection | M12x1<br>4 pin<br>acc. to EN 60947-5-2<br>Round shape<br>Plug |
| Fastening type | With throughway bores |
| installation position | arbitrary |
| Pneumatic connection | G1/4 |
| Product weight [g] | 194 |
| Housing material | Aluminium die casting |
| Switch contact material | <span class="farbe" style="background-color:#EDEDED"></span> silver |
| Settings range threshold value [bar] | 1 to 12 |
| Protection category | IP65 |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| Manufacturer Nr. | PEV-1/4-B-M12 |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568007966 |
| Weight | 0.185000 |
| HS-Code | 85365080 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Werkstoff | Aluminium |
| Betriebsdruck max [bar] | 12.000000 |
| Pneumatischer Anschluss | G1/4 |
| Schutzart | IP65 |
