Sub-Base VMPA1-FB-AP-4-1-T1-RV - Festo 8034549
Festo fitting or line component for fast, leak-tight and pressure-resistant compressed-air connections.
Net
excl. VAT
€78.17
Item
FES-8034549
Manufacturer no.
VMPA1-FB-AP-4-1-T1-RV
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Festo fitting or line component for fast, leak-tight and pressure-resistant compressed-air connections. The key technical data of this genuine Festo article are listed below.
Technical data
| Product weight [g] | 190,0 |
|---|---|
| Material information | RoHs compliant |
| Width [mm] | 49,0 |
| Length [mm] | 107,3 |
| Pitch dimension [mm] | 10,5 |
| Max. number of valve spaces | 4 |
| Operating pressure [bar] | -0.9 to 10 |
| Control pressure [bar] | 3 to 8 |
| Corrosion resistant class KBK | 0 - No corrosion stressing |
| ambient temperature [°C] | -5 to 50 |
| Connection plate material | Aluminium die casting |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Weight | 0.19 kg |
| Manufacturer | Festo |
| Manufacturer Nr. | VMPA1-FB-AP-4-1-T1-RV |
| EAN | 4052568429225 |
| HS-Code | 84819000 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Condition of article | New |
| Article authenticity | Original product |
| Medium | Compressed air |
| Corrosion resistance class CRC | 0 - No corrosion stressing |
| Operating conditions | ISO 8573-1 |
| Series | VMPA1 |
| Betriebsdruck max [bar] | 10 |
| Temperature (max.) | 50 |
