Regulator Plate VMPA2-B8-R3C2-C-10 - Festo 543344
Festo air-preparation unit for clean, regulated compressed air that protects downstream components.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Festo air-preparation unit for clean, regulated compressed air that protects downstream components. The key technical data of this genuine Festo article are listed below.
Technical data
| Product weight [g] | 180,0 |
|---|---|
| Material information | RoHs compliant |
| Corrosion resistant class KBK | 1 - low corrosion stress |
| ambient temperature [°C] | -5 to 50 |
| Build.width [mm] | 21,0 |
| installation position | arbitrary |
| Pneumatic height linking | pressure regulator for 4 |
| Controller function | Output pressure constant<br>With relieving |
| Selection pressure gauge | Possible |
| Pressure regulation range [bar] | 2 to 8.5 |
| Input pressure 1 [bar] | 0.5 to 10 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Protection category | IP65<br>acc. to IEC 60529 |
| Max. tightening torque [Nm] | 0,65 |
| Fastening type height linking | on linking plate |
| Pressure gauge connection | With Holding clamp |
| Control panel material | PA |
| Seals material | NBR |
| Controller housing material | PA |
| Weight | 0.23 kg |
| Manufacturer | Festo |
| Manufacturer Nr. | VMPA2-B8-R3C2-C-10 |
| EAN | 4052568181796 |
| HS-Code | 84811099 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Condition of article | New |
| Article authenticity | Original product |
| Regelbereich max. [bar] | 8,5 |
| Dichtmaterial | NBR |
| Medium | Compressed air |
| Corrosion resistance class CRC | 1 - low corrosion stress |
| Mounting position | arbitrary |
| Certification | IEC 60529 |
| Operating conditions | ISO 8573-1 |
| Series | VMPA2 |
| Protection class (IP) | IP65 |
| Temperature (max.) | 50 |
