Genuine Festo accessory for exact mounting, fastening and extension of the associated component.
End Plate VMPAL-EPL-IPO32 - Festo 575667
FESTO
Original product
Net price (excl. VAT)
€160.10
Item
FES-575667
Manufacturer no.
VMPAL-EPL-IPO32
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.VMPAL-EPL-IPO32
EAN4052568224042
Customs tariff number84819000
ConditionNew
Article
FES-575667
Frequently Bought Together
-
This Item:
€160.10
-
Multi-Pin Plug CPV18-VI-P2-1/4-B - Festo 175632
€102.53
-
Sub-Base VMPA14-IC-AP-S-1-EX1E - Festo 8023669
€82.49
Total price
Genuine Festo accessory for exact mounting, fastening and extension of the associated component. The key technical data of this genuine Festo article are listed below.
| Width [mm] | 64,8 |
| Length [mm] | 107,3 |
| Max. number of valve spaces | 32 |
| Valve island structure | Valve sizes mixable |
| Operating pressure [bar] | -0.9 to 10 |
| Control pressure [bar] | 3 to 8 |
| Corrosion resistant class KBK | 3 - severe corrosion stress |
| ambient temperature [°C] | -5 to 50 |
| Product weight [g] | 170,00 |
| Material information | RoHs compliant |
| Max. number of valve coils | 32 |
| Nominal operating voltage DC [V] | 24 |
| Protection category | IP65<br>IP67 |
| Information about protection category | In mounted condition |
| Electrical connection 1, function | IO-Link |
| Electrical connection 1, connection type | Plug |
| Electrical connection 1, connection technology | M12x1 A coded to EN 61076-2-101 |
| Electrical connection 1, number of pins / wires | 5 |
| End plate material | PPA reinforced |
| Reverse polarity protection | for operating voltage |
| installation position | arbitrary |
| Diagnosis | Under-voltage Load supplies |
| Intrinsic power input at load voltage [mA] | 30 |
| Intrinsic power input at operating voltage [mA] | 30 |
| Report | I-port<br>IO-Link |
| Bearing temperature [°C] | -20 to 40 |
| IO-Link, report | Device V 1.0 |
| IO-Link, communication mode | COM2 (38,4 kBaud), COM3 (230,4 kBaud) |
| IO-Link, port type | B |
| IO-Link, number of ports | 1 |
| IO-Link, process data width OUT | 1 - 4 Byte |
| IO-Link, minimum cycle time | Device 3.2 ms |
| LED display bus specific | 1x Kommunikationsstatus |
| Norm | EN 61076-2-101 |
|---|---|
| Manufacturer Nr. | VMPAL-EPL-IPO32 |
| Manufacturer | Festo |
| EAN | 4052568224042 |
| Weight | 0.190000 |
| HS-Code | 84819000 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 50 |
| Betriebsdruck max [bar] | 10.000000 |
| Protection rating | IP65 |
| Series | VMPAL |
| Operating voltage | 24 V DC |
| Corrosion resistance class CRC | 3 - severe corrosion stress |
| Mounting position | arbitrary |
| Position sensing | No |
