Transport trolleys
Reeco workstations
Material that must not become charged moves between stores, line and test floor. Reeco transport trolleys are dissipative throughout, from the coating through the shelves to the castors, so earthing through the shop floor is maintained.
The range covers shelf trolleys with two or three levels, platform trolleys for bulky parts, enclosed and lockable transport trolleys with up to eight slide-in shelves, and mobile workstations with a keyboard shelf. Capacities run from 150 to 2000 kg and castor diameters from 75 to 125 mm.
| Type | Shelves | Capacity | Castors |
|---|---|---|---|
| Classic shelf trolley | 2 or 3 | 150 kg | 75 mm |
| Reinforced shelf trolley | 2 or 3 | 300 kg | 80 mm |
| Platform trolley | 1 | 300 kg | 125 mm |
| Enclosed transport trolley | 4 to 8 | - | 125 mm |
| Mobile workstation | 3 plus keyboard shelf | - | - |
| Pipe and profile rack | - | 2000 kg | mobile, foldable |
Typical applications: Material flow between stores and the placement line, buffering assemblies ahead of test stations, transport between buildings in a lockable body, mobile test and measurement positions at the line, and cutting and supply of profiles and pipes.
