Festo fitting or line component for fast, leak-tight and pressure-resistant compressed-air connections.
Addressing Cable KASI-ADR - Festo 18960
FESTO Original product
Net price (excl. VAT)
€98.78
Item FES-18960
Manufacturer no. KASI-ADR
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.KASI-ADR
EAN4052568113186
Customs tariff number85444290
ConditionNew
Article
FES-18960
Frequently Bought Together
- This Item: €98.78
- Connecting Cable NEBV-S1W37-E-5-LE26 - Festo 539244 €148.68
- Connecting Cable KMC-1-24-10-LED - Festo 193459 €28.35
Total price
Festo fitting or line component for fast, leak-tight and pressure-resistant compressed-air connections. The key technical data of this genuine Festo article are listed below.
| Operating voltage range DC [V] | 0 to 48 |
| Operating voltage range AC [V] | 0 to 48 |
| Protection category | IP20 |
| ambient temperature [°C] | -40 to 85 |
| Ambient temperature for moving cable placements [°C] | -25 to 80 |
| Cable sleeve material | Rubber mixture |
| Cable shield colour | <span class="farbe" style="background-color:#FFED00"></span> yellow |
| Report | As interface |
| Construction set up | T-distributor with cable both sides |
| Distributor type | 2 to 1 |
| Additional functions | Connection of the programming device to a AS-Interface component via AS-I flat cable |
| Line designation | Without sign holder |
| Electrical connection 1, function | Field device screen |
| Electrical connection 1, design | Angular |
| Electrical connection 1, connection type | socket / container / …. |
| Electrical connection 1, cable output | Angled |
| Electrical connection 1, connection technology | As interface |
| Electrical connection 1, number of pins / wires | 2 |
| Electrical connection 1, occupied pin / wire | 2 |
| Electrical connection 1, fastening type | plugged |
| Electrical connection 2, function | Field device screen |
| Electrical connection 2, design | round |
| Electrical connection 2, connection type | socket / container / …. |
| Electrical connection 2, cable output | straight |
| Electrical connection 2, connection technology | M12x1 A coded to EN 61076-2-101 |
| Electrical connection 2, number of pins / wires | 4 |
| Electrical connection 2, occupied pin / wire | 2 |
| Electrical connection 2, fastening type | plugged |
| Electrical connection 3, function | Control screen |
| Electrical connection 3, design | round |
| Electrical connection 3, connection type | Plug |
| Electrical connection 3, cable output | Angled |
| Electrical connection 3, connection technology | M12x1 A coded to EN 61076-2-101 |
| Electrical connection 3, number of pins / wires | 4 |
| Electrical connection 3, occupied pin / wire | 2 |
| Electrical connection 3, fastening type | plugged |
| Current carrying capacity at 40°C [A] | 3 |
| Surge voltage strength [kV] | 0,5 |
| Cable length 1 [MTR] | 2,4 |
| Cable length 2 [MTR] | 0,1 |
| Line properties | Standard |
| Test conditions line | Test conditions on request |
| Cable set up | 2x1,5 |
| Conductor - nominal cross-section [mm²] | 1,5 |
| Information about protection category | In mounted condition |
| Material information | RoHs compliant |
| Degree of contamination | 2 |
| Housing colour | <span class="farbe" style="background-color:#000000"></span> black |
| Manufacturer Nr. | KASI-ADR |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568113186 |
| Weight | 0.220000 |
| HS-Code | 85444290 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 85 |
| Protection rating | IP20 |
| Design | T-distributor with cable both sides |
| Position sensing | No |
