End-Position Controll SPC11-INC - Festo 537321
Festo air-preparation unit for clean, regulated compressed air that protects downstream components.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Festo air-preparation unit for clean, regulated compressed air that protects downstream components. The key technical data of this genuine Festo article are listed below.
Technical data
| Data backup | Flash memory |
|---|---|
| Control signal | Output error ready<br>Output position 1/2/3/4<br>Input position 1/2/3/4<br>Input remote / teach / left / right |
| Display | 3 digits<br>Red colour<br>Seven segment display |
| Operating element | 3 buttons<br>Foil keyboard |
| Output fuses | Electronic<br>max. trigger current 500 mA<br>Via sum of all outputs |
| Quantity digital outputs | 5 |
| Quantity digital inputs | 8 |
| Design outputs | No galvanic separation<br>acc. to IEC 61131-2<br>Positive logic (PNP) |
| Design inputs | No galvanic separation<br>acc. to IEC 61131-2<br>Positive logic (PNP) |
| Debounce time inputs [ms] | 20 |
| Max. power input with proportional valve [A] | 1,1 |
| Max. power input without proportional valve [mA] | 80 |
| Nominal operating voltage DC [V] | 24 |
| Power consumption input [mA] | 4 |
| Current carrying capacity per output [mA] | 100 |
| Permitted voltage oscillations | ± 25 % |
| Permission | RCM mark |
| CE certificate (see declaration of conformity) | to EU EMC directive |
| Continuous impact strength DIN&EC 68 parts 2-82 | Tested to severity class 2 |
| Relative humidity | 0 - 95 %<br>Not condensing |
| Protection category | IP65<br>acc. to IEC 60529 |
| Oscillation strength to DIN/IEC 68 part 2-6 | Tested to severity class 1 |
| ambient temperature [°C] | 0 to 50 |
| Product weight [g] | 400 |
| Electrical connection type | SUB-D<br>15 pin<br>Plug |
| Electrical connection: proportional valve | M9<br>7-polig<br>Dose |
| Electrical connection: path measurement system | M12<br>8 pin<br>socket / container / …. |
| Weight | 0.38 kg |
| Manufacturer | Festo |
| Manufacturer Nr. | SPC11-INC |
| EAN | 4052568172633 |
| HS-Code | 85371091 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Condition of article | New |
| Article authenticity | Original product |
| Norm | DIN EN 61131-2 |
| Certification | IEC 60529 |
| Operating voltage | 24 V DC |
| Series | SPC11 |
| Protection class (IP) | IP65 |
| Temperature (max.) | 50 |
