Festo VZBF-3/4-P1-20-D-2-F0304-V15V# (4810852) Ball Valve

Festo
€1,099.00
Excl. 19% VAT , excl. Shipping Cost
Article
FES-4810852

Manufacturer Nr.
VZBF-3/4-P1-20-D-2-F0304-V15V#
Ball Valve
Add to Wish List Add to Compare
main product photo
The product may differ from the illustration
Frequently Bought Together
Total price
Construction set up 2-way ball valve
Actuation type Mechanical
Sealing principle Soft
installation position arbitrary
Fastening type pipe installation
Fitting connection Flange to ANSI B16.5 class 150
Switching position display Carriage direction = flow direction
Flange drilling screen F0304
Inside diameter [mm] 20
Nominal width DN 20
Valve function 2/2
Flow direction Reversible
Nominal pressure fitting 20
Break-out torque at a pressure difference nominal fitting pressure PN [Nm] 10
Based on standard ISO 5211
ANSI B16.5 class 150
medium Compressed air acc. to ISO8573-1:2010 [-:-:-]
Inert gasses
Neutral liquids
Water
Steam
Medium temperature [°C] -20 to 200
Flow Kv [m³/h] 15,6
Material information LABS containing materials included
RoHs compliant
Housing material Cast stainless steel
Material number housing 1.4408
Seals material FPM
PCTFE
PTFE
Graphite
Ball material Cast stainless steel
Material number ball 1.4408
Shaft material High-alloyed stainless steels
Material number shaft 1.4401
Product weight [g] 1.950
Permission API607
CRN
Corrosion resistant class KBK 4 - particularly severe corrosion stress
More Information
Manufacturer Nr. VZBF-3/4-P1-20-D-2-F0304-V15V#
Manufacturer Festo
EAN 4052568275587
Weight 0.100000
HS-Code 84818081
GPSR manufacturer information Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity Original product
Condition of article New
