Festo VZXA-B-TS6-25-M2-V13T-8.3-K-4# (8060530) Angle Seat Val.

Festo
€29,154.00
Excl. 19% VAT , excl. Shipping Cost
Article
FES-8060530

Manufacturer Nr.
VZXA-B-TS6-25-M2-V13T-8.3-K-4#
Angle Seat Val.
Add to Wish List Add to Compare
main product photo
The product may differ from the illustration
Frequently Bought Together
Total price
Construction set up Poppet valve with piston actuator
Actuation type pneumatic
installation position arbitrary
Fastening type pipe installation
Line connection Threaded muff G1 acc. to DIN ISO 228
Valve function 2/2
Flow direction Not reversible
Medium pressure [bar] 0 to 8.3
Reset mode Mechanical spring
Control type Remote controlled
Pneumatic connection female thread G1/8
Betriebsdruck Mpa [MPa] 0.5 to 1
Operating pressure [bar] 5 to 10
Operating pressure [psi] [psi] 72,5 bis 145
medium Hydraulic oil on the basis of mineral oil
Inert gases
mineral oil
Neutral liquids
Water
Filtered compressed air, filter porosity 200 µm
steam
Flow direction Lower valve seat, for gas and liquid media
Control of the medium On/off mode
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Max. viscosity [mm²/s] 600
Medium temperature [°C] -10 to 180
ambient temperature [°C] 0 to 60
Flow Kv [m³/h] 20,3
Material information LABS containing materials included
RoHs compliant
Instrument housing material Cast stainless steel
Material number instrument housing 1.4409
Seals material FPM
Spindle seal material PTFE
Seat seal material PTFE
Product weight [g] 2.150
Permission CRN
CE certificate (see declaration of conformity) to EU machinery directive
Certified awarding point CRN0C20829.5C
TÜV 968/V 1039.00/18
Safety Integrity Level (SIL) SIL 2
Probability of Failure per Hour in [1/h]. 1.36e-007
PED (Probability of failure on demand) 0.000595
Actuator dimensions [mm] 46
Stroke [mm] 17
Control function Closed due to spring force, NC
Position detection With Mechanical display
Actuator housing material Cast stainless steel
Material number actuator housing 1.4408
Bearing temperature [°C] -10 to 60
Protection category IP65
IP67
IP69K
Piston rod material High-alloyed stainless steels
Cover material Cast stainless steel
More Information
Manufacturer Nr. VZXA-B-TS6-25-M2-V13T-8.3-K-4#
Manufacturer Festo
EAN 4052568290450
Weight 2.400000
HS-Code 84818073
GPSR manufacturer information Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity Original product
Condition of article New
