High bay and industrial lights
Workplace lighting
This category covers high bay, warehouse and continuous row luminaires from Glamox for production, logistics and workshop areas. The range spans the LINDOX-2000, LINDOX-4000 and LINDOX-6000 continuous row systems, the ANDOX-4468, MADOX-4468 and REDOX-4468 high bay luminaires and compact series such as COSMO, MIKO, i80, i85 and I65-4. Luminous flux runs from 4000 lm to 50000 lm, power input from 20 W to 178 W and the protection rating from IP20 to IP67. The focus lies on 4000 K and Ra 80, alongside 3000 K, 5000 K, Tunable White and versions carrying the TEC marking for ESD areas.
Quick selection
These filters narrow the range by control, design, luminous flux and protection rating.
DALI dimmableCentral dimming, scenes and daylight-linked control.Digital control interface
Switched (HF)Simple wiring, the luminaire sits directly on the circuit.No control line needed
LINDOX continuous rowsUnbroken lines above rack aisles and assembly lines.LINDOX-2000, LINDOX-4000, LINDOX-6000
4468 high bay luminairesWide beam luminaires for production and storage.ANDOX-4468, MADOX-4468, REDOX-4468
Protection rating IP66For dusty surroundings and cleaning with a water jet.Dust tight and jet proof
Tunable WhiteWarm white in the morning, neutral white during the day.Adjustable colour temperature
High luminous fluxFor tall mounting heights in halls and warehouses.18000 lm to 50000 lm
Versions for ESD areasLuminaires for electrostatic protected working areas.TEC marking
| Criterion | What to check | Available here |
|---|---|---|
| Mounting height and luminous flux | The higher the luminaire hangs, the more luminous flux is needed for the same illuminance. | 4000 lm to 50000 lm, with the bulk at 6250 lm, 8750 lm and 12500 lm |
| Design and series | Continuous rows for long rack aisles, pendant luminaires above single work zones, recessed units in suspended ceilings. | LINDOX-2000, LINDOX-4000 and LINDOX-6000 continuous rows, ANDOX-4468, MADOX-4468 and REDOX-4468 high bay luminaires, compact series COSMO, MIKO, i80, i85, I65-2, I65-4 and I65-6; as pendant, surface mounted and recessed versions |
| Protection rating | A dry hall manages with IP20, dusty or damp areas call for IP65 and above. | IP20 to IP67, most often IP66, also IP20, IP65, IP67, IP54 and IP44 |
| Colour temperature | 4000 K is the standard in production and storage, 3000 K suits staff and ancillary rooms. | Mainly 4000 K, alongside 3000 K, 5000 K and Tunable White |
| Control | DALI allows central dimming and scenes, switched versions are simpler to install. | DALI dimmable, switched (HF), Tunable White |
| Colour rendering | Ra 80 covers storage and production, Ra 90 is meant for inspection and visual workstations. | Predominantly Ra 80, single versions with Ra 90 and Ra 70 |
| Power input | Relevant for sizing the circuits and for running costs. | 20 W to 178 W, commonly 39 W, 55 W and 78 W |
| Supply voltage | Check whether the luminaire is connected to an extra low voltage system. | Versions for 48 V |
| ESD suitability | In electrostatic protected areas the marking of the luminaire is the deciding factor. | Versions with TEC marking |
- How much luminous flux does a hall need?
- The luminous flux required rises with the mounting height. The range runs from 4000 lm for low storage areas to 50000 lm for tall halls, with the familiar classes 6250 lm, 8750 lm, 12500 lm and 18000 lm in between. Power input moves between 20 W and 178 W.
- When is protection rating IP66 required?
- IP66 is intended for dusty areas and for cleaning with a water jet, for example in production and wet rooms. Protection ratings here run from IP20 for dry halls through IP44, IP54 and IP65 up to IP67.
- What does DALI control offer?
- DALI lets single luminaires and groups be dimmed centrally and combined into scenes. It is the basis for daylight-linked control and presence detection. Switched versions (HF) work without a control line and are simpler to install.
- What does Tunable White mean?
- With Tunable White the colour temperature can be adjusted during operation, for example from warm white in the morning to neutral white during the day. Fixed colour temperatures are available as 3000 K, 4000 K and 5000 K.
- Which series work as a continuous row?
- The LINDOX-2000, LINDOX-4000 and LINDOX-6000 series are designed as continuous rows and are installed above rack aisles and assembly lines. For single light points the ANDOX-4468, MADOX-4468 and REDOX-4468 high bay luminaires are the better fit.
