Input Module CPX-16DE - Festo 543815
FESTO
Original product
Net price (excl. VAT)
€148.07
Item
FES-543815
Manufacturer no.
CPX-16DE
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.CPX-16DE
EAN4052568182540
Customs tariff number85389099
ConditionNew
Article
FES-543815
Frequently Bought Together
-
This Item:
€148.07
-
End Plate CPX-EPR-EV-X - Festo 576313
€89.23
-
End Plate VMPA-FB-EPLM-G - Festo 552286
€131.66
Total price
Festo pneumatic component for industrial automation and compressed-air applications in proven quality. The key technical data of this genuine Festo article are listed below.
| Dimensions W x L x H | 50 mm x 107 mm x 50 mm<br>(Incl. linking block and connectors) |
| Diagnosis | Kurzschluss/Überlast pro Kanal |
| Parameterising | Eingangsentprellzeit<br>Signalverlängerungszeit<br>Überwachung Modul<br>Verhalten nach Kurzschluss |
| LED displays | 1 Sammeldiagnose<br>16 Kanalstatus |
| Operating voltage range DC [V] | 18 to 30 |
| Intrinsic power input at operating voltage | Type 15 mA |
| Nominal operating voltage DC [V] | 24 |
| Potential separation channel - internal bus | no |
| Potential separation channel - channel | no |
| Corrosion resistant class KBK | (In integrated condition)<br>1 - low corrosion stress |
| Bearing temperature [°C] | -20 to 70 |
| Protection category | Depends on connection block |
| ambient temperature [°C] | -5 to 50 |
| Product weight [g] | 41,0 |
| Housing material | PC<br>PA reinforced |
| Quantity inputs | 16 |
| Input debouncing time | 3 ms (0.1 ms, 10 ms, 20 ms parameterisable) |
| Fuse (short circuit) | Internal electronic fuse Per module |
| Max. cumulative current inputs per module [A] | 1,8 |
| Switch level | Signal 0: <= 5 V<br>Signal 1: >= 11 V |
| Characteristic curves inputs | IEC1131-T2 |
| Switching logic inputs | PNP (Positive switching) |
| Norm | IEC 1131 |
|---|---|
| Manufacturer Nr. | CPX-16DE |
| Manufacturer | Festo |
| EAN | 4052568182540 |
| Weight | 0.047000 |
| HS-Code | 85389099 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 50 |
| Material | Polyamide (PA) |
| Series | CPX |
| Operating voltage | 24 V DC |
| Corrosion resistance class CRC | 1 - low corrosion stress |
| Position sensing | No |
