The product may differ from the illustration
Festo air-preparation unit for clean, regulated compressed air that protects downstream components.
End-Position Controll CPX-CMPX-C-1-H1 - Festo 548931
FESTO
Original product
Net price (excl. VAT)
€403.44
Excl. 19% VAT ,
excl. Shipping Cost
Available
Fast shipping
Item
FES-548931
Manufacturer no.
CPX-CMPX-C-1-H1
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.CPX-CMPX-C-1-H1
EAN4052568190231
Customs tariff number85371091
ConditionNew
Article
FES-548931
Frequently Bought Together
-
This Item:
€403.44Excl. 19% VAT , excl. Shipping Cost
-
Proportional Directio MPYE-5-3/8-420-B - Festo 161981
€855.90Excl. 19% VAT , excl. Shipping Cost
-
Displacement Encoder MLO-POT-360-TLF - Festo 152627
€440.82Excl. 19% VAT , excl. Shipping Cost
Total price
Festo air-preparation unit for clean, regulated compressed air that protects downstream components. The key technical data of this genuine Festo article are listed below.
| Dimensions W x L x H | 50 mm x 107 mm x 55 mm |
| Diagnosis | Modulorientierte Diagnose<br>über lokale 7-Segment-Anzeige |
| Max. number of modules | 10 |
| Display | Seven segment display |
| Operating element | 3 buttons |
| Operating voltage range DC [V] | 18 to 30 |
| Load voltage range DC [V] | 20 to 30 |
| Nominal operating voltage DC [V] | 24 |
| Nominal load voltage DC [V] | 24 |
| Power input in nominal operating voltage [mA] | 80 |
| Permitted load current [A] | 2,5 |
| Continuous impact strength DIN&EC 68 parts 2-29 | Tested to severity class 2 |
| Relative humidity | 5 - 95 %<br>Not condensing |
| Protection category | IP65<br>acc. to IEC 60529 |
| Oscillation strength to DIN/IEC 68 part 2-6 | Tested to severity class 2 |
| ambient temperature [°C] | -5 to 50 |
| Product weight [g] | 140 |
| Axes per strand | 1 |
| Quantity axis strands | 1 |
| Electrical connection: control interface | M9<br>5 pin<br>socket / container / …. |
| Cable length [MTR] | <= 30 m |
| Control interface | Digital<br>Closing resistance integrated<br>CAN bus with Festo protocol |
| Housing material | PA reinforced |
| Manufacturer Nr. | CPX-CMPX-C-1-H1 |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568190231 |
| Weight | 0.140000 |
| HS-Code | 85371091 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Werkstoff | Polyamid (PA) |
| Schutzart | IP65 |
