Festo pneumatic cylinder for precise linear motion and defined force in automation.
Mini Slide DGSC-6-10-P-L - Festo 569793
FESTO
Original product
Net price (excl. VAT)
€248.81
Item
FES-569793
Manufacturer no.
DGSC-6-10-P-L
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.DGSC-6-10-P-L
EAN4052568216450
Customs tariff number84123100
ConditionNew
Article
FES-569793
Frequently Bought Together
-
This Item:
€248.81
-
Mini Slide DGSL-20-20-P1A - Festo 544015
€671.06
-
Mini Slide DGSL-20-30-P1A - Festo 544016
€702.70
Total price
Festo pneumatic cylinder for precise linear motion and defined force in automation. The key technical data of this genuine Festo article are listed below.
| Stroke [mm] | 10 |
| Piston diameter | 6 mm |
| Operating mode actuator unit | Joch |
| Dampening | P: Elastic silencer rings / plates double-sided |
| installation position | arbitrary |
| Guide | Ball cage guide |
| Construction set up | Joch kinematics |
| Position detection | without |
| Operating pressure [bar] | 1 to 6 |
| Repeatability | 0.2 mm |
| Principle of operation | double acting |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| ambient temperature [°C] | 10 to 50 |
| Max. force Fy [N] | 20 |
| Max. force Fz [N] | 20 |
| Max. torque Mx [Nm] | 0,3 |
| Max. torque My [Nm] | 0,4 |
| Max. torque Mz [Nm] | 0,4 |
| Theoretical force at 6 bar, Return flow [N] | 12,7 |
| Theoretical force at 6 bar, flow [N] | 17 |
| Moving mass [g] | 17 |
| Product weight [g] | 42 |
| Fastening type | With Female thread and dowel pin |
| Pneumatic connection | M3 |
| Material information | Copper and PTFE-free<br>RoHs compliant |
| Seals material | NBR |
| Housing material | High-alloyed stainless steels |
| Piston rod material | High-alloyed stainless steels |
| Operating conditions | ISO 8573-1 |
|---|---|
| Manufacturer Nr. | DGSC-6-10-P-L |
| Manufacturer | Festo |
| EAN | 4052568216450 |
| Weight | 0.060000 |
| HS-Code | 84123100 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 50 |
| Material | Stainless steel |
| Bore (mm) | 6.000000 |
| Betriebsdruck max [bar] | 6.000000 |
| Pneumatic connection | M3 |
| Hub [mm] | 10 |
| Dichtmaterial | NBR |
| Medium | Compressed air |
| Funktion | double-acting |
| Corrosion resistance class CRC | 2 - moderate corrosion stress |
| Mounting position | arbitrary |
| Design | Joch kinematics |
| Position sensing | No |
| Cushioning | P: Elastic silencer rings / plates double-sided |
