Festo pneumatic cylinder for precise linear motion and defined force in automation.
Mini Slide DGSL-16-150-P1A - Festo 543998
FESTO
Original product
Net price (excl. VAT)
€1,050.61
Item
FES-543998
Manufacturer no.
DGSL-16-150-P1A
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.DGSL-16-150-P1A
EAN4052568183417
Customs tariff number84123100
ConditionNew
Article
FES-543998
Frequently Bought Together
-
This Item:
€1,050.61
-
Mini Slide SLS-16-30-P-A - Festo 170502
€488.47
-
Mini Slide DGST-16-125-E1A - Festo 8078860
€598.58
Total price
Festo pneumatic cylinder for precise linear motion and defined force in automation. The key technical data of this genuine Festo article are listed below.
| Stroke [mm] | 150 |
| Alignable end position range / Length front [mm] | 72,5 |
| Alignable end position range / Length rear [mm] | 39,5 |
| Piston diameter | 20 mm |
| Operating mode actuator unit | Joch |
| Dampening | P1: Elastic silencer rings / plates double-sided With fixed limit stop |
| installation position | arbitrary |
| Guide | Ball cage guide |
| Construction set up | Joch<br>Kolben<br>Kolbenstange<br>Schlitten |
| Position detection | For proximity switch |
| Operating pressure [bar] | 1 to 8 |
| Max. speed [m/s] | 0,8 |
| Repeatability | ±0.01 mm |
| Principle of operation | double acting |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 0 - No corrosion stressing |
| ambient temperature [°C] | 0 to 60 |
| Impact energy at the end positions [J] | 0,120 |
| Dampening length [mm] | 4,2 |
| Max. force Fy [N] | 2.900 |
| Max. force Fz [N] | 2.900 |
| Max. torque Mx [Nm] | 50 |
| Max. torque My [Nm] | 43,0 |
| Max. torque Mz [Nm] | 43,0 |
| Theoretical force at 6 bar, Return flow [N] | 158 |
| Theoretical force at 6 bar, flow [N] | 188 |
| Moving mass [g] | 910 |
| Product weight [g] | 2.114 |
| Alternative connections | See product drawing |
| Fastening type | With throughway bores |
| Pneumatic connection | M5 |
| Material information | Copper and PTFE-free<br>RoHs compliant |
| Cover material | Aluminium wrought alloy |
| Seals material | HNBR |
| Housing material | Aluminium wrought alloy |
| Piston rod material | High-alloyed stainless steels |
| Operating conditions | ISO 8573-1 |
|---|---|
| Manufacturer Nr. | DGSL-16-150-P1A |
| Manufacturer | Festo |
| EAN | 4052568183417 |
| Weight | 2.200000 |
| HS-Code | 84123100 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 60 |
| Material | Aluminium |
| Bore (mm) | 20.000000 |
| Betriebsdruck max [bar] | 8.000000 |
| Pneumatic connection | M5 |
| Series | DGSL |
| Hub [mm] | 150 |
| Dichtmaterial | HNBR |
| Medium | Compressed air |
| Funktion | double-acting |
| Corrosion resistance class CRC | 0 - No corrosion stressing |
| Mounting position | arbitrary |
| Design | Yoke, piston, piston rod, carriage |
| Position sensing | Yes |
| Cushioning | P1: Elastic silencer rings / plates double-sided With fixed limit stop |
