Festo DHEB-41-E-U-E-L (1320817) Bellows Gripper

Name: Festo DHEB-41-E-U-E-L (1320817) Bellows Gripper
Brand: Festo
SKU: FES-1320817
Price: 331 EUR
Availability: InStock

€331.00

Excl. 19% VAT , excl. Shipping Cost

Article

FES-1320817

Manufacturer Nr.

DHEB-41-E-U-E-L

Bellows Gripper

The product may differ from the illustration

Frequently Bought Together

This Item: Festo DHEB-41-E-U-E-L (1320817) Bellows Gripper
€331.00
Excl. 19% VAT , excl. Shipping Cost
Festo DHDS-16-A-NC (1259492) Three-Point Gripper
€63,953.00
Excl. 19% VAT , excl. Shipping Cost
Festo HGRT-50-A-G2 (563915) Radial Gripper
€123,952.00
Excl. 19% VAT , excl. Shipping Cost

Total price

size	41
Bellows stroke [mm]	15,5
Min. diameter to be gripped [mm]	42,0
Max. diameter to be gripped [mm]	54,0
installation position	arbitrary
Principle of operation	single action closed
Construction set up	Contact membrane Force controlled movement cycle
Guide	Base guide
Position detection	For proximity switch
Operating pressure [bar]	4 to 8
reset pressure [bar]	< 1 bar
Max. working frequency gripper [Hz]	<= 4 Hz
Min. opening time a 6 bar [ms]	30
Min. closing time at 6 bar [ms]	70
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium	Oiled operation possible (required in further operations)
Corrosion resistant class KBK	2 - moderate corrosion stress
ambient temperature [°C]	5 to 60
Centre exchange interval for bellows [Mio SP]	0,5
Guideline payload [KGM]	1,20
Product weight [g]	300
Fastening type	With Male thread With locking nut Selectively:
Pneumatic connection	G1/8
Material information	LABS containing materials included RoHs compliant
Bellows material	EPDM
Housing material	aluminium anodized

More Information
Manufacturer Nr.	DHEB-41-E-U-E-L
Manufacturer	Festo
EAN	4052568230371
Weight	0.330000
HS-Code	84798997
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity	Original product
Condition of article	New
