Festo Elfc-Kf-80-600 (8062829) Guide Axis
€41,588.00
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-8062829
Manufacturer Nr.
ELFC-KF-80-600
Guide Axis
Frequently Bought Together
-
This Item:
€41,588.00Excl. 19% VAT , excl. Shipping Cost
-
Festo Eamm-U-86-S48-87A-102 (8059004) Parallel Kit
€63,493.00Excl. 19% VAT , excl. Shipping Cost
-
Festo Eads-F-D32-42A (1561527) Seal-Set
€8,021.00Excl. 19% VAT , excl. Shipping Cost
Total price
| Working stroke [mm] | 600 |
| size | 80 |
| Stroke reserve [mm] | 0 |
| installation position | arbitrary |
| Guide | ball guide |
| Construction set up | Guide |
| Max. acceleration [m/s²] | 500 |
| Max. speed [m/s] | 1,5 |
| Power-on time | 100 % |
| Corrosion resistant class KBK | 0 - No corrosion stressing |
| Protection category | IP40 |
| ambient temperature [°C] | 0 to 50 |
| Flat torque 2nd grade ly [mm4] | 1.37e+006 |
| Flat torque 2nd grade lz [mm4] | 1.66e+006 |
| Max. force Fy [N] | 900 |
| Max. force Fz [N] | 2.700 |
| Max. torque Mx [Nm] | 59,8 |
| Max. torque My [Nm] | 56,2 |
| Max. torque Mz [Nm] | 56,2 |
| Torsional moment of inertia to [mm4] | 90.500 |
| Pushing force [N] | 15,00 |
| Fy for theoretical lifetime of 100 km (pure guide observation) [N] | 3.312 |
| Fz for theoretical lifetime of 100 km (purely management observation) [N] | 9.936 |
| Mx for theoretical lifetime of 100 km (Purely management observation) [Nm] | 220 |
| My for theoretical lifetime of 100 km (Purely management observation) [Nm] | 207 |
| Mz for theoretical lifetime of 100 km (Purely management observation) [Nm] | 207 |
| Moving mass [g] | 815 |
| Weight supplement per 10 mm stroke [g] | 73 |
| Closing cover material | Die cast aluminium, painted |
| Profile material | Aluminium wrought alloy, anodised |
| Material information | LABS containing materials included RoHs compliant |
| Masking tape material | High-alloyed stainless steels |
| Cover material | Die cast aluminium, painted |
| Carriage guide material | Steel |
| Guide carriage material | Steel |
| Carriage material | Aluminium die casting |
| Manufacturer Nr. | ELFC-KF-80-600 |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568296582 |
| Weight | 6.000000 |
| HS-Code | 84821090 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
