Festo HGDD-80-A-G1 (1163050) Three-Point Gripper
€168,566.00
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-1163050
Manufacturer Nr.
HGDD-80-A-G1
Three-Point Gripper
Frequently Bought Together
-
This Item:
€168,566.00Excl. 19% VAT , excl. Shipping Cost
-
Festo HGDT-50-A (540868) Three-Point Gripper
€98,014.00Excl. 19% VAT , excl. Shipping Cost
-
Festo HGPL-40-80-A-B (3361490) Parallel Gripper
€206,137.00Excl. 19% VAT , excl. Shipping Cost
Total price
| size | 80 |
| Stroke per gripper jaw [mm] | 12 |
| Max. exchange precision [mm] | <= 0,2 mm |
| Max. gripper jaw play ax, ay [deg] | <= 0,1 deg |
| Max. gripper jaw play Sz [mm] | <= 0,05 mm |
| Rotational symmetry [mm] | <= 0,2 mm |
| Repeatability grippers [mm] | <= 0,05 mm |
| Quantity Gripper jaws | 3 |
| installation position | arbitrary |
| Principle of operation | double acting |
| Gripper function | 3 point |
| Construction set up | Inclined plane Force controlled movement cycle |
| Position detection | For proximity switch |
| Operating pressure [bar] | 4 to 8 |
| Operating pressure blocking air [bar] | 0 to 0.5 |
| Max. working frequency gripper [Hz] | <= 4 Hz |
| Min. opening time a 6 bar [ms] | 72 |
| Min. closing time at 6 bar [ms] | 246 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| Protection category | IP65 |
| ambient temperature [°C] | 5 to 60 |
| Mass inertia [kg/cm²] | 109,000 |
| Max. force on gripper jaws Fz static [N] | 3.600 |
| Max. torque on gripper jaws Mx static [Nm] | 100 |
| Max. torque on gripper jaws My static [Nm] | 65 |
| Max. torque on gripper jaws Mz static [Nm] | 75 |
| Lubrication interval guide elements [Mio SP] | 5 |
| Max. mass per external griper finger [g] | 790 |
| Product weight [g] | 4.788 |
| Fastening type | With Throughway bore and dowel pin With Female thread and dowel pin Selectively: |
| Pneumatic connection blocking air | G1/8 |
| Pneumatic connection | G1/8 |
| Material information | RoHs compliant |
| Cover cap material | High-alloyed stainless steels |
| Housing material | Aluminium wrought alloy Smooth anodised |
| Gripper jaws material | hardened Steel |
| Gripping force safety | When opening |
| Manufacturer Nr. | HGDD-80-A-G1 |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568227975 |
| Weight | 5.000000 |
| HS-Code | 84798997 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
