The product may differ from the illustration
Festo gripper for secure handling and positioning of workpieces in automated processes.
Parallel Gripper HGPL-63-150-A-B - Festo 3361494
FESTO Original product
Net price (excl. VAT)
€5,793.86
Item FES-3361494
Manufacturer no. HGPL-63-150-A-B
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.HGPL-63-150-A-B
EAN4052568269319
Customs tariff number84798997
ConditionNew
Article
FES-3361494
Frequently Bought Together
- This Item: €5,793.86
- Three-Point Gripper HGDT-35-A-F-G1 - Festo 560181 €975.11
- Angle Gripper HGWM-12-EZ-G6 - Festo 185702 €248.93
Total price
Festo gripper for secure handling and positioning of workpieces in automated processes. The key technical data of this genuine Festo article are listed below.
| size | 63 |
| Stroke per gripper jaw [mm] | 150 |
| Max. exchange precision [mm] | < 0,2 mm |
| Max. gripper jaw play ax, ay [deg] | < 0.2 deg |
| Max. gripper jaw play Sz [mm] | < 0,05 mm |
| Rotational symmetry [mm] | <= 0,2 mm |
| Repeatability grippers [mm] | < 0,03 mm |
| Quantity Gripper jaws | 2 |
| installation position | arbitrary |
| Principle of operation | double acting |
| Gripper function | Parallel |
| Construction set up | Double piston<br>Guide<br>Piston pusher<br>T-shape<br>Toothed rack/pinion |
| Position detection | For proximity switch |
| Open total gripping force at 6 bar [N] | 2.466 |
| Close total gripping force at 6 bar [N] | 2.742 |
| Operating pressure [bar] | 3 to 8 |
| Max. working frequency gripper [Hz] | < 1 Hz |
| Min. opening time a 6 bar [ms] | 1.020 |
| Min. closing time at 6 bar [ms] | 850 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| ambient temperature [°C] | 5 to 60 |
| Open gripper jaws at gripping force of 6 bar [N] | 1.233 |
| Close gripper jaws at gripping force at 6 bar [N] | 1.371 |
| Mass inertia [kg/cm²] | 2.247,54 |
| Max. force on gripper jaws Fz static [N] | 9.000 |
| Max. torque on gripper jaws Mx static [Nm] | 300 |
| Max. torque on gripper jaws My static [Nm] | 200 |
| Max. torque on gripper jaws Mz static [Nm] | 250 |
| Lubrication interval guide elements [Mio SP] | 5 |
| Max. mass per external griper finger [g] | 940 |
| Product weight [g] | 18.100 |
| Fastening type | Female thread and centring sleeve<br>With Throughway bore and centring sleeve |
| Pneumatic connection | G1/8 |
| Material information | Copper and PTFE-free<br>RoHs compliant |
| Housing material | aluminium<br>Smooth anodised |
| Gripper jaws material | hardened<br>Steel |
| Manufacturer Nr. | HGPL-63-150-A-B |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568269319 |
| Weight | 19.000000 |
| HS-Code | 84798997 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Werkstoff | Aluminium |
| Betriebsdruck max [bar] | 8.000000 |
| Pneumatischer Anschluss | G1/8 |
