Festo KVI-CP-3-WS-WD-5 (540330) Connecting Cable
€6,899.00
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-540330
Manufacturer Nr.
KVI-CP-3-WS-WD-5
Connecting Cable
Frequently Bought Together
-
This Item:
€6,899.00Excl. 19% VAT , excl. Shipping Cost
-
Festo MPYE-5-M5-420-B (162959) Proportional Directio
€74,573.00Excl. 19% VAT , excl. Shipping Cost
-
Festo MLO-POT-750-TLF (152631) Displacement Encoder
€62,473.00Excl. 19% VAT , excl. Shipping Cost
Total price
| Cable length [MTR] | 5,00 |
| Additional functions | Contact 3 of the socket 1 mm accelerated |
| Line designation | With Accessories |
| Connection frequency | 500 |
| Electrical connection 1, function | Field device screen |
| Electrical connection 1, design | round |
| Electrical connection 1, connection type | socket / container / …. |
| Electrical connection 1, cable output | Angled |
| Electrical connection 1, connection technology | M9x0,5 |
| Electrical connection 1, number of pins / wires | 5 |
| Electrical connection 1, occupied pin / wire | 5 |
| Electrical connection 1, fastening type | Screw lock |
| Electrical connection 2, function | Control screen |
| Electrical connection 2, design | round |
| Electrical connection 2, connection type | Plug |
| Electrical connection 2, cable output | Angled |
| Electrical connection 2, connection technology | M9x0,5 |
| Electrical connection 2, number of pins / wires | 5 |
| Electrical connection 2, occupied pin / wire | 5 |
| Electrical connection 2, fastening type | Screw lock |
| Operating voltage range DC [V] | 0 to 30 |
| Current carrying capacity at 40°C [A] | 1,6 |
| Surge voltage strength [kV] | 1,5 |
| Line properties | Cable track capable |
| Test conditions line | Test conditions on request |
| Bending radius, moving cable placement [mm] | >= 75 mm |
| Cable diameter [mm] | 5,5 |
| Cable set up | 2x0,25+2x0,34+0,49 Shielded |
| Conductor - nominal cross-section [mm²] | 0.25 0.34 0.49 |
| Protection category | IP65 IP67 |
| Information about protection category | In mounted condition |
| ambient temperature [°C] | -20 to 80 |
| Ambient temperature for moving cable placements [°C] | -5 to 80 |
| Material information | RoHs compliant |
| Degree of contamination | 1 |
| Cable sleeve material | TPE-U(PUR) |
| Cable shield colour | Light grey |
| Product weight [g] | 257,8 |
| Housing material | PA PBT TPE-U(PUR) |
| Housing colour | black |
| Corrosion resistant class KBK | 1 - low corrosion stress |
| Information about current load rating at 40 °C | 2.3 A for 0,34 mm² 3.6 A for 0,49 mm² |
| Screw lock material | brass, nickel-plated |
| Plug contacts material | Bronze gold-plated Brass, gold-plated |
| Insulation sleeve material | TPE-U(PUR) |
| Manufacturer Nr. | KVI-CP-3-WS-WD-5 |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568090395 |
| Weight | 0.260000 |
| HS-Code | 85444290 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
