The product may differ from the illustration
Festo fitting or line component for fast, leak-tight and pressure-resistant compressed-air connections.
Connecting Cable KVI-CP-3-GS-GD-5 - Festo 540333
FESTO
Original product
Net price (excl. VAT)
€75.26
Excl. 19% VAT ,
excl. Shipping Cost
Available
Fast shipping
Item
FES-540333
Manufacturer no.
KVI-CP-3-GS-GD-5
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.KVI-CP-3-GS-GD-5
EAN4052568090418
Customs tariff number85444290
ConditionNew
Article
FES-540333
Frequently Bought Together
-
This Item:
€75.26Excl. 19% VAT , excl. Shipping Cost
-
Displacement Encoder MLO-POT-500-TLF - Festo 152629
€549.11Excl. 19% VAT , excl. Shipping Cost
-
Mounting CP-TS-HS-35 - Festo 170169
€9.95Excl. 19% VAT , excl. Shipping Cost
Total price
Festo fitting or line component for fast, leak-tight and pressure-resistant compressed-air connections. The key technical data of this genuine Festo article are listed below.
| Cable length [MTR] | 5,00 |
| Additional functions | Contact 3 of the socket 1 mm accelerated |
| Line designation | With Accessories |
| Connection frequency | 500 |
| Electrical connection 1, function | Field device screen |
| Electrical connection 1, design | round |
| Electrical connection 1, connection type | socket / container / …. |
| Electrical connection 1, cable output | straight |
| Electrical connection 1, connection technology | M9x0,5 |
| Electrical connection 1, number of pins / wires | 5 |
| Electrical connection 1, occupied pin / wire | 5 |
| Electrical connection 1, fastening type | Screw lock |
| Electrical connection 2, function | Control screen |
| Electrical connection 2, design | round |
| Electrical connection 2, connection type | Plug |
| Electrical connection 2, cable output | straight |
| Electrical connection 2, connection technology | M9x0,5 |
| Electrical connection 2, number of pins / wires | 5 |
| Electrical connection 2, occupied pin / wire | 5 |
| Electrical connection 2, fastening type | Screw lock |
| Operating voltage range DC [V] | 0 to 30 |
| Current carrying capacity at 40°C [A] | 1,6 |
| Surge voltage strength [kV] | 1,5 |
| Line properties | Cable track capable |
| Test conditions line | Test conditions on request |
| Bending radius, moving cable placement [mm] | >= 75 mm |
| Cable diameter [mm] | 5,5 |
| Cable set up | 2x0,25+2x0,34+0,49<br>Shielded |
| Conductor - nominal cross-section [mm²] | 0.25<br>0.34<br>0.49 |
| Protection category | IP65<br>IP67 |
| Information about protection category | In mounted condition |
| ambient temperature [°C] | -20 to 80 |
| Ambient temperature for moving cable placements [°C] | -5 to 80 |
| Material information | RoHs compliant |
| Degree of contamination | 1 |
| Cable sleeve material | TPE-U(PUR) |
| Cable shield colour | <span class="farbe" style="background-color:#EDEDED"></span> Light grey |
| Product weight [g] | 255,4 |
| Housing material | PA<br>PBT<br>TPE-U(PUR) |
| Housing colour | <span class="farbe" style="background-color:#000000"></span> black |
| Corrosion resistant class KBK | 1 - low corrosion stress |
| Information about current load rating at 40 °C | 2.3 A for 0,34 mm²<br>3.6 A for 0,49 mm² |
| Screw lock material | brass, nickel-plated |
| Plug contacts material | Bronze gold-plated<br>Brass, gold-plated |
| Insulation sleeve material | TPE-U(PUR) |
| Manufacturer Nr. | KVI-CP-3-GS-GD-5 |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568090418 |
| Weight | 0.255000 |
| HS-Code | 85444290 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Werkstoff | PBT |
| Schutzart | IP65 |
