Festo pneumatic cylinder for precise linear motion and defined force in automation.
Mini Slide DGSL-25-200-EA - Festo 570212
FESTO Original product
Net price (excl. VAT)
€1,153.40
Item FES-570212
Manufacturer no. DGSL-25-200-EA
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.DGSL-25-200-EA
EAN4052568217075
Customs tariff number84123100
ConditionNew
Article
FES-570212
Frequently Bought Together
- This Item: €1,153.40
- Mini Slide DGSL-12-30-P1A - Festo 543971 €639.47
- Mini Slide DGST-25-30-Y12A - Festo 8085191 €568.70
Total price
Festo pneumatic cylinder for precise linear motion and defined force in automation. The key technical data of this genuine Festo article are listed below.
| Stroke [mm] | 200 |
| Alignable end position range / Length front [mm] | 66,5 |
| Alignable end position range / Length rear [mm] | 5,5 |
| Piston diameter | 32 mm |
| Operating mode actuator unit | Joch |
| Dampening | Short elastic dampening rings / plates both sides |
| installation position | arbitrary |
| Guide | Ball cage guide |
| Construction set up | Joch<br>Kolben<br>Kolbenstange<br>Schlitten |
| Position detection | For proximity switch |
| Operating pressure [bar] | 1 to 8 |
| Max. speed [m/s] | 0,8 |
| Repeatability | 0.3 mm |
| Principle of operation | double acting |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 0 - No corrosion stressing |
| ambient temperature [°C] | 0 to 60 |
| Impact energy at the end positions [J] | 0,550 |
| Dampening length [mm] | 1,3 |
| Max. force Fy [N] | 4.800 |
| Max. force Fz [N] | 4.800 |
| Max. torque Mx [Nm] | 130 |
| Max. torque My [Nm] | 80,0 |
| Max. torque Mz [Nm] | 80,0 |
| Theoretical force at 6 bar, Return flow [N] | 415 |
| Theoretical force at 6 bar, flow [N] | 483 |
| Moving mass [g] | 2.432 |
| Product weight [g] | 6.220 |
| Alternative connections | See product drawing |
| Fastening type | With throughway bores |
| Pneumatic connection | G1/8 |
| Material information | Copper and PTFE-free<br>RoHs compliant |
| Cover material | Aluminium wrought alloy |
| Seals material | HNBR |
| Housing material | Aluminium wrought alloy |
| Piston rod material | High-alloyed stainless steels |
| Manufacturer Nr. | DGSL-25-200-EA |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568217075 |
| Weight | 6.000000 |
| HS-Code | 84123100 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Werkstoff | Aluminium |
| Bohrung (mm) | 32.000000 |
| Betriebsdruck max [bar] | 8.000000 |
| Pneumatischer Anschluss | G1/8 |
| Hub [mm] | 200.000000 |
