Festo DGSL-25-200-PA (544038) Mini Slide

Festo
€112,593.00
Excl. 19% VAT , excl. Shipping Cost
Article
FES-544038

Manufacturer Nr.
DGSL-25-200-PA
Mini Slide
Add to Wish List Add to Compare
main product photo
The product may differ from the illustration
Frequently Bought Together
Total price
Stroke [mm] 200
Alignable end position range / Length front [mm] 110,0
Alignable end position range / Length rear [mm] 49,0
Piston diameter 32 mm
Operating mode actuator unit Joch
Dampening P: Elastic silencer rings / plates double-sided
installation position arbitrary
Guide Ball cage guide
Construction set up Joch
Kolben
Kolbenstange
Schlitten
Position detection For proximity switch
Operating pressure [bar] 1 to 8
Max. speed [m/s] 0,8
Repeatability 0.3 mm
Principle of operation double acting
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium Oiled operation possible (required in further operations)
Corrosion resistant class KBK 0 - No corrosion stressing
ambient temperature [°C] 0 to 60
Impact energy at the end positions [J] 0,550
Dampening length [mm] 1,3
Max. force Fy [N] 4.800
Max. force Fz [N] 4.800
Max. torque Mx [Nm] 130
Max. torque My [Nm] 80,0
Max. torque Mz [Nm] 80,0
Theoretical force at 6 bar, Return flow [N] 415
Theoretical force at 6 bar, flow [N] 483
Moving mass [g] 2.432
Product weight [g] 6.351
Alternative connections See product drawing
Fastening type With throughway bores
Pneumatic connection G1/8
Material information Copper and PTFE-free
RoHs compliant
Cover material Aluminium wrought alloy
Seals material HNBR
Housing material Aluminium wrought alloy
Piston rod material High-alloyed stainless steels
More Information
Manufacturer Nr. DGSL-25-200-PA
Manufacturer Festo
EAN 4052568183813
Weight 7.000000
HS-Code 84123100
GPSR manufacturer information Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity Original product
Condition of article New
