Festo Elgc-Bs-Kf-32-100-8P (8061477) Spindle Axis
€61,817.00
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-8061477
Manufacturer Nr.
ELGC-BS-KF-32-100-8P
Spindle Axis
Frequently Bought Together
-
This Item:
€61,817.00Excl. 19% VAT , excl. Shipping Cost
-
Festo Egc-70-800-Tb-Kf-0H-Gk (3012496) Toothed Belt Axis
€126,953.00Excl. 19% VAT , excl. Shipping Cost
-
Festo Egc-120-300-Bs-25P-Kf-0& (3013580) Spindle Axis
€211,815.00Excl. 19% VAT , excl. Shipping Cost
Total price
| Working stroke [mm] | 100 |
| size | 32 |
| Stroke reserve [mm] | 0 |
| Spindle diameter [mm] | 8 |
| Spindle pitch [mm/U] | 8 |
| installation position | arbitrary |
| Guide | ball guide |
| Construction set up | Electro-mechanical linear axis With Ball screw |
| Motor type | Step motor Servo motor |
| Spindle type | Ball screw drive |
| Max. acceleration [m/s²] | 15 |
| Max. speed [1/min] | 4.500 |
| Max. speed [m/s] | 0,6 |
| Repeatability | ±0.015 mm |
| Protection category | IP40 |
| ambient temperature [°C] | 0 to 50 |
| Flat torque 2nd grade ly [mm4] | 38000 |
| Flat torque 2nd grade lz [mm4] | 45000 |
| Empty run torque at maximum movement speed [Nm] | 0,040 |
| Empty run torque at minimum movement speed [Nm] | 0,020 |
| Max. force Fy [N] | 150 |
| Max. force Fz [N] | 300 |
| Fy for theoretical lifetime of 100 km (pure guide observation) [N] | 552 |
| Fz for theoretical lifetime of 100 km (purely management observation) [N] | 1.104 |
| Max. torque Mx [Nm] | 1,3 |
| Max. torque My [Nm] | 1,1 |
| Max. torque Mz [Nm] | 1,1 |
| Mx for theoretical lifetime of 100 km (Purely management observation) [Nm] | 5 |
| My for theoretical lifetime of 100 km (Purely management observation) [Nm] | 4 |
| Mz for theoretical lifetime of 100 km (Purely management observation) [Nm] | 4 |
| Max. feed force Fx [N] | 40 |
| Torsional moment of inertia to [mm4] | 1.700 |
| Mass inertia JH per metre stroke [kg/cm²] | 0,02218 |
| Mass inertia JL per kg usable load [kg/cm²] | 0,016211 |
| Mass inertia JO [kg/cm²] | 0,00274 |
| Feed constant [mm/U] | 8 |
| Moving mass [g] | 83,4 |
| Weight supplement per 10 mm stroke [g] | 18 |
| Dynamic bending (load moved) | 0.05% of the axis length, maximum 0.5 mm |
| Static bending (load at standstill) | 0.1 % of the axis length |
| Interface code actuator | V25 |
| Closing cover material | Die cast aluminium, painted |
| Profile material | Aluminium wrought alloy, anodised |
| Material information | LABS containing materials included RoHs compliant |
| Masking tape material | High-alloyed stainless steels |
| Actuator cover material | Die cast aluminium, painted |
| Carriage guide material | Steel |
| Guide carriage material | Steel |
| Carriage material | Aluminium die casting |
| Spindle nut material | Steel |
| Spindle material | Steel |
| Manufacturer Nr. | ELGC-BS-KF-32-100-8P |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568295660 |
| Weight | 0.490000 |
| HS-Code | 84799070 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
