Flanged Pressure Gaug FMA-63-0,25-C - Festo 225783
Festo pneumatic component for industrial automation and compressed-air applications in proven quality.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Festo pneumatic component for industrial automation and compressed-air applications in proven quality. The key technical data of this genuine Festo article are listed below.
Technical data
| Display range [bar] [bar] | 0 to 0.25 |
|---|---|
| Complies to standard | EN 837-3 |
| Nominal size pressure gauge | 63 |
| Fastening type | Front panel integration |
| Operating medium | Fluid media<br>Gas-type media |
| Operating pressure [bar] | 0 to 0.25 |
| Factor alternating strain | 0.9 |
| Measurement precision class | 1,6 |
| Protection category | IP43 |
| Medium temperature [°C] | -20 to 80 |
| ambient temperature [°C] | -20 to 60 |
| Connection position | Back side centred |
| Pneumatic connection | G1/4 |
| Stud material | Brass |
| Housing material | Steel |
| Window material | PMMA |
| Fastening ring material | Steel |
| Product weight [g] | 120 |
| Information about operating and control medium | No acetylene<br>No oxygen |
| Display range [psi] [psi] | 0 to 3.6 |
| Factor continuous loading | 0.75 |
| Screws material | Steel |
| Weight | 0.22 kg |
| Manufacturer | Festo |
| Manufacturer Nr. | FMA-63-0,25-C |
| EAN | 4052568161125 |
| HS-Code | 90262040 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Condition of article | New |
| Article authenticity | Original product |
| Material | Steel |
| Gewinde | G 1/4 |
| Norm | DIN EN 837-3 |
| Series | FMA |
| Betriebsdruck max [bar] | 0.25 |
| Protection class (IP) | IP43 |
| Temperature (max.) | 60 |
