Festo HGDD-35-A-G2 (1163039) Three-Point Gripper
€104,597.00
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-1163039
Manufacturer Nr.
HGDD-35-A-G2
Three-Point Gripper
Frequently Bought Together
-
This Item:
€104,597.00Excl. 19% VAT , excl. Shipping Cost
-
Festo DHEB-51-E-D-S-L (1320763) Bellows Gripper
€30,759.00Excl. 19% VAT , excl. Shipping Cost
-
Festo HGPT-40-A-B-F-G1 (560220) Parallel Gripper
€8,554.00Excl. 19% VAT , excl. Shipping Cost
Total price
| size | 35 |
| Stroke per gripper jaw [mm] | 4 |
| Max. exchange precision [mm] | <= 0,2 mm |
| Max. gripper jaw play ax, ay [deg] | <= 0,1 deg |
| Max. gripper jaw play Sz [mm] | <= 0,05 mm |
| Rotational symmetry [mm] | <= 0,2 mm |
| Repeatability grippers [mm] | <= 0,03 mm |
| Quantity Gripper jaws | 3 |
| installation position | arbitrary |
| Principle of operation | double acting |
| Gripper function | 3 point |
| Construction set up | Inclined plane Force controlled movement cycle |
| Position detection | For proximity switch |
| Operating pressure [bar] | 4 to 8 |
| Operating pressure blocking air [bar] | 0 to 0.5 |
| Max. working frequency gripper [Hz] | <= 4 Hz |
| Min. opening time a 6 bar [ms] | 81 |
| Min. closing time at 6 bar [ms] | 42 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| Protection category | IP65 |
| ambient temperature [°C] | 5 to 60 |
| Mass inertia [kg/cm²] | 1,370 |
| Max. force on gripper jaws Fz static [N] | 300 |
| Max. torque on gripper jaws Mx static [Nm] | 12 |
| Max. torque on gripper jaws My static [Nm] | 8 |
| Max. torque on gripper jaws Mz static [Nm] | 8 |
| Lubrication interval guide elements [Mio SP] | 5 |
| Max. mass per external griper finger [g] | 57 |
| Product weight [g] | 370 |
| Fastening type | With Throughway bore and dowel pin With Female thread and dowel pin Selectively: |
| Pneumatic connection blocking air | M3 |
| Pneumatic connection | M5 |
| Material information | Copper and PTFE-free RoHs compliant |
| Cover cap material | High-alloyed stainless steels |
| Housing material | Aluminium wrought alloy Smooth anodised |
| Gripper jaws material | hardened Steel |
| Gripping force safety | When closing |
| Manufacturer Nr. | HGDD-35-A-G2 |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568227869 |
| Weight | 0.400000 |
| HS-Code | 84798997 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
