Swivel/Gripper Unit HGDS-PP-20-P1-A-B - Festo 1187962
Festo rotary actuator for defined swivel motion and positioning in automation.
Net
excl. VAT
€1,490.08
Item
FES-1187962
Manufacturer no.
HGDS-PP-20-P1-A-B
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Festo rotary actuator for defined swivel motion and positioning in automation. The key technical data of this genuine Festo article are listed below.
Technical data
| size | 20 |
|---|---|
| Settings range swivel angle [deg] | 0 to 210 |
| Stroke per gripper jaw [mm] | 7,0 |
| Max. gripper jaw play ax, ay [deg] | 0,1 |
| Max. gripper jaw play Sz [mm] | 0,02 |
| Swivel angle [deg] | 210 |
| Quantity Gripper jaws | 2 |
| Dampening rotary actuator | Elastic dampening rings / plates double-sided, End positions adjustable, With fixed limit stop |
| installation position | arbitrary |
| Fine adjustment rotary actuator [deg] | -6,0 |
| Principle of operation | double acting |
| Gripper function | Parallel |
| Construction set up | With Parallel gripper and gripper actuator<br>rotary actuator |
| Position detection grippers | With proximity switch |
| Position detection rotary actuator | With proximity switch |
| Operating pressure [bar] | 3 to 8 |
| Max. swivel frequency at 6 bar [Hz] | 2,0 |
| Min. opening time a 6 bar [ms] | 60 |
| Min. closing time at 6 bar [ms] | 70 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| ambient temperature [°C] | 5 to 60 |
| Open gripper jaws at gripping force of 6 bar [N] | 96 |
| Open total gripping force at 6 bar [N] | 192 |
| Close gripper jaws at gripping force at 6 bar [N] | 84 |
| Close total gripping force at 6 bar [N] | 168 |
| Max. force on gripper jaws Fz static [N] | 250 |
| Max. torque on gripper jaws Mx static [Nm] | 22 |
| Max. torque on gripper jaws My static [Nm] | 22 |
| Max. torque on gripper jaws Mz static [Nm] | 22 |
| Theoretical torque at 6 bar [Nm] | 2,50 |
| Max. mass per external griper finger [g] | 100 |
| Product weight [g] | 1.260 |
| Fastening type | With Dovetail-slot<br>Selectively:<br>Female thread and centring sleeve<br>With Throughway bore and centring sleeve |
| Pneumatic connection | M5 |
| Material information | RoHs compliant |
| Drive shaft material | Steel |
| Cover material | POM<br>aluminium |
| Seals material | NBR |
| Housing material | Aluminium wrought alloy |
| Gripper jaws material | High-alloyed stainless steels |
| Weight | 1.3 kg |
| Manufacturer | Festo |
| Manufacturer Nr. | HGDS-PP-20-P1-A-B |
| EAN | 4052568228262 |
| HS-Code | 84798997 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Condition of article | New |
| Article authenticity | Original product |
| Material | Aluminium |
| Gewinde | M5 |
| Dichtmaterial | NBR |
| Medium | Compressed air |
| Funktion | double-acting |
| Corrosion resistance class CRC | 2 - moderate corrosion stress |
| Mounting position | arbitrary |
| Design | With Parallel gripper and gripper actuator, rotary actuator |
| Operating conditions | ISO 8573-1 |
| Series | HGDS |
| Betriebsdruck max [bar] | 8 |
| Temperature (max.) | 60 |
