Festo MPYE-5-3/8-420-B (161981) Proportional Directio

Name: Festo MPYE-5-3/8-420-B (161981) Proportional Directio
Brand: Festo
SKU: FES-161981
Price: 81869 EUR
Availability: InStock

€81,869.00

Excl. 19% VAT , excl. Shipping Cost

Article

FES-161981

Manufacturer Nr.

MPYE-5-3/8-420-B

Proportional Directio

The product may differ from the illustration

Frequently Bought Together

This Item: Festo MPYE-5-3/8-420-B (161981) Proportional Directio
€81,869.00
Excl. 19% VAT , excl. Shipping Cost
Festo SPC11-POT-TLF (192216) End-Position Controll
€55,875.00
Excl. 19% VAT , excl. Shipping Cost
Festo KMPYE-AIF-1-GS-GD-2 (170238) Connecting Cable
€9,782.00
Excl. 19% VAT , excl. Shipping Cost

Total price

Nominal width [mm]	10
Actuation type	Electrical
Sealing principle	Hard
installation position	arbitrary
Construction set up	Piston pusher
Reset mode	Spring magnetic
Safety instructions	Safety position MPYE: Move to the blocked centre position if there is a supply line break.
Control type	Direct
Flow direction	Not reversible
Valve function	5/3 closed
Reverse polarity protection	For target value
Operating pressure [bar]	0 to 10
b-value	0.21
C-value [l/sbar]	9,00
Normal nominal flow [l/min]	2.000
Limit frequency [Hz]	70
Max. hysteresis [%]	0,4
Operating voltage range DC [V]	17 to 30
residual ripple	5 %
TARGET / ACTUAL value	Current type 4 - 20 mA
Permission	RCM mark
KC-mark	KC-EMV
CE certificate (see declaration of conformity)	to EU EMC directive
Operating medium	Compressed air to ISO 8573-1:2010 [6:4:4]
Information about operating and control medium	Oiled operation not possible
Corrosion resistant class KBK	2 - moderate corrosion stress
Medium temperature [°C]	5 to 40
Protection category	IP65
ambient temperature [°C]	0 to 50
Product weight [g]	685
Electrical connection	M12x1 4 pin Round shape Plug
Fastening type	With throughway bores
Pneumatic connection 1	G3/8
Pneumatic connection 2	G3/8
Pneumatic connection 3	G3/8
Pneumatic connection 4	G3/8
Pneumatic connection 5	G3/8
Material information	RoHs compliant
Cover material	ABS Coated
Seals material	NBR
Housing material	aluminium anodized

More Information
Manufacturer Nr.	MPYE-5-3/8-420-B
Manufacturer	Festo
EAN	4052568129491
Weight	0.800000
HS-Code	84812090
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity	Original product
Condition of article	New
