On-Off Valve MS12-EM-G - Festo 541495
Festo valve for fast, reliable control of compressed-air direction and flow.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Festo valve for fast, reliable control of compressed-air direction and flow. The key technical data of this genuine Festo article are listed below.
Technical data
| Construction set up | Piston pusher |
|---|---|
| Actuation type | Manually |
| Exhaust function | Cannot be throttled |
| Control type | Direct |
| Valve function | 3/2 bistable |
| Operating pressure [bar] | 0 to 20 |
| Normal nominal flow [l/min] | 25000 to 32000 |
| Operating medium | Compressed air to ISO8573-1:2010 [-:-:-] |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| Material information | Copper and PTFE-free |
| Medium temperature [°C] | -10 to 60 |
| ambient temperature [°C] | -10 to 60 |
| Fastening type | pipe installation<br>With Accessories<br>Selectively: |
| installation position | arbitrary |
| Flow direction | Not reversible |
| Product weight [g] | 3.900 |
| Pneumatic connection 1 | Battery module |
| Pneumatic connection 2 | Battery module |
| Pneumatic connection 3 | G1 |
| Control air supply | Internal |
| Seals material | NBR |
| Housing material | Aluminium die casting |
| Weight | 4.8 kg |
| Manufacturer | Festo |
| Manufacturer Nr. | MS12-EM-G |
| EAN | 4052568179670 |
| HS-Code | 84812090 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Condition of article | New |
| Article authenticity | Original product |
| Material | Aluminium |
| Dichtmaterial | NBR |
| Medium | Compressed air |
| Funktion | 3/2 bistable |
| Durchfluss [l/min] | 2500032000 |
| Corrosion resistance class CRC | 2 - moderate corrosion stress |
| Mounting position | arbitrary |
| Design | Piston pusher |
| Operating conditions | ISO 8573-1 |
| Series | MS12 |
| Betriebsdruck max [bar] | 20 |
| Temperature (max.) | 60 |
