Festo air-preparation unit for clean, regulated compressed air that protects downstream components.
Service Unit Combinat MSB4-1/4:C3J1F3-WP - Festo 542294
FESTO Original product
Net price (excl. VAT)
€271.67
Item FES-542294
Manufacturer no. MSB4-1/4:C3J1F3-WP
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.MSB4-1/4:C3J1F3-WP
EAN4052568180386
Customs tariff number84811005
ConditionNew
Article
FES-542294
Frequently Bought Together
- This Item: €271.67
- Service Unit Combina MSB6-1/2:C3:J120:F12-WP - Festo 8042671 €325.57
- Service Unit Combinat MSB6-3/8-FRC5:J1M1 - Festo 530292 €149.78
Total price
Festo air-preparation unit for clean, regulated compressed air that protects downstream components. The key technical data of this genuine Festo article are listed below.
| size | 4 |
| Model series | MS |
| Actuation fuse | Rotary button with stopper<br>With Accessories lockable |
| installation position | vertical ± 5° |
| Filter porosity [µm] | 40 |
| Condensate drain | Manually rotating |
| Construction set up | Branching module<br>Switch on valve<br>Filter regulator with pressure gauge |
| Controller function | Output pressure constant<br>With Return current behaviour<br>With relieving<br>With Pre-pressure compensation |
| Clamp protection | Plastic basket |
| pressure display | with pressure gauge |
| Operating pressure [bar] | 0.8 to 14 |
| Pressure regulation range [bar] | 0.5 to 12 |
| Normal nominal flow [l/min] | 1.300 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4]<br>Inert gases |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| Bearing temperature [°C] | -10 to 60 |
| Food compatibility | See expanded material information |
| Air purity class at the output | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Medium temperature [°C] | -10 to 60 |
| ambient temperature [°C] | -10 to 60 |
| Product weight [g] | 1.500 |
| Fastening type | With Accessories |
| Pneumatic connection 1 | G1/4 |
| Pneumatic connection 2 | G1/4 |
| Pneumatic connection 3 | G1/4 |
| Housing material | Aluminium die casting |
| Clamps material | PC |
| Manufacturer Nr. | MSB4-1/4:C3J1F3-WP |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568180386 |
| Weight | 1.100000 |
| HS-Code | 84811005 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 60 |
| Material | Aluminium |
| Betriebsdruck max [bar] | 14.000000 |
| Pneumatic connection | G1/4 |
| Series | MSB4 |
| Regelbereich max. [bar] | 12 |
| Medium | Compressed air, neutral gases |
| Durchfluss [l/min] | 1300 |
| Filterfeinheit [µm] | 40 |
| Kondensatablass | manual rotary |
| Corrosion resistance class CRC | 2 - moderate corrosion stress |
| Mounting position | vertical ± 5° |
| Design | Branching module, Switch on valve, Filter regulator with pressure gauge |
| Position sensing | No |
