Multi-Pin Plug Socket NECA-S1G9-P9-MP1 - Festo 548719
FESTO Original product
Net price (excl. VAT)
€70.35
Item FES-548719
Manufacturer no. NECA-S1G9-P9-MP1
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.NECA-S1G9-P9-MP1
EAN4052568093327
Customs tariff number85366990
ConditionNew
Article
FES-548719
Frequently Bought Together
- This Item: €70.35
- Plug Socket NTSD-GD-9-M12-5POL-RK - Festo 538999 €25.16
- Multi-Pin Plug Socket NECA-S1G9-P9-MP3 - Festo 552703 €70.35
Total price
Festo pneumatic component for industrial automation and compressed-air applications in proven quality. The key technical data of this genuine Festo article are listed below.
| Fastening type | With throughway bores |
| Product weight [g] | 60 |
| Electrical connection 1 | Socket, Sub-D, 9 pin |
| Electrical connection 2 | Screw clamp, 9 pin |
| Operating voltage range DC [V] | 21.6 to 26.4 |
| Nominal operating voltage DC [V] | 24 |
| Current carrying capacity at 40°C [A] | 1 |
| Permitted cable diameter [mm] | 5 to 10 |
| Connection cross-section [mm²] | 0.34 to 1 |
| Information about connection cross-section | 0.34-0.5 mm² with wire end sleeves |
| Protection category | IP65<br>acc. to IEC 60529 |
| ambient temperature [°C] | 0 to 50 |
| Bearing temperature [°C] | -20 to 70 |
| Relative humidity | 95 %<br>Not condensing |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| Housing material | PA reinforced |
| Locking nut material | Brass |
| Screws material | Steel |
| Seals material | NBR |
| Manufacturer Nr. | NECA-S1G9-P9-MP1 |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568093327 |
| Weight | 0.085000 |
| HS-Code | 85366990 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 50 |
| Material | Polyamide (PA) |
| Protection rating | IP65 |
| Operating voltage | 24 V DC |
| Dichtmaterial | NBR |
| Corrosion resistance class CRC | 2 - moderate corrosion stress |
| Position sensing | No |
