Plug FBS-SUB-9-BU-IB-B - Festo 532218
Festo pneumatic component for industrial automation and compressed-air applications in proven quality.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Festo pneumatic component for industrial automation and compressed-air applications in proven quality. The key technical data of this genuine Festo article are listed below.
Technical data
| Product weight [g] | 60,0 |
|---|---|
| Permitted cable diameter [mm] | 5 to 10 |
| Protection category | IP65<br>IP67<br>In mounted condition<br>acc. to IEC 60529 |
| ambient temperature [°C] | 0 to 50 |
| Material information | RoHs compliant |
| Housing material | PA reinforced |
| Locking nut material | Brass |
| Width | 20 mm |
| Height | 62 mm |
| Length | 61 mm |
| Report | Interbus |
| Additional functions | RBST bridge integrated |
| Fieldbus interface | 1x 5 spring tension clamps |
| Bearing temperature [°C] | -20 to 70 |
| Relative humidity | 95 %<br>Not condensing |
| Screws material | Steel |
| Seals material | NBR |
| Weight | 0.075 kg |
| Manufacturer | Festo |
| Manufacturer Nr. | FBS-SUB-9-BU-IB-B |
| EAN | 4052568086053 |
| HS-Code | 85366990 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Condition of article | New |
| Article authenticity | Original product |
| Material | Polyamide (PA) |
| Dichtmaterial | NBR |
| Certification | IEC 60529 |
| Series | FBS |
| Protection class (IP) | IP65 |
| Temperature (max.) | 50 |
