Festo SLS-6-5-P-A (170485) Mini Slide

Festo
€31,827.00
Excl. 19% VAT , excl. Shipping Cost
Article
FES-170485

Manufacturer Nr.
SLS-6-5-P-A
Mini Slide
Add to Wish List Add to Compare
main product photo
The product may differ from the illustration
Frequently Bought Together
Total price
Stroke [mm] 5
Piston diameter 6 mm
Operating mode actuator unit Joch
Dampening P: Elastic silencer rings / plates double-sided
installation position arbitrary
Guide Ball cage guide
Construction set up Joch
Kolben
Kolbenstange
Schlitten
Kugel-Käfigführung
Position detection For proximity switch
Operating pressure [bar] 1.5 to 10
Principle of operation double acting
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium Oiled operation possible (required in further operations)
Corrosion resistant class KBK 0 - No corrosion stressing
ambient temperature [°C] -20 to 60
Impact energy at the end positions [J] 0,008
Max. force Fy [N] 220
Max. force Fz [N] 220
Max. torque Mx [Nm] 0,6
Max. torque My [Nm] 0,6
Max. torque Mz [Nm] 0,5
Theoretical force at 6 bar, Return flow [N] 13
Theoretical force at 6 bar, flow [N] 17
Moving mass [g] 28
Product weight [g] 97
Alternative connections See product drawing
Fastening type With throughway bores
Pneumatic connection M5
Material information Copper and PTFE-free
Cover material Aluminium wrought alloy
Seals material HNBR
Housing material Aluminium wrought alloy
Piston rod material High-alloyed stainless steels
More Information
Manufacturer Nr. SLS-6-5-P-A
Manufacturer Festo
EAN 4052568138912
Weight 0.120000
HS-Code 84123100
GPSR manufacturer information Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity Original product
Condition of article New
