Festo valve for fast, reliable control of compressed-air direction and flow.
Pneumatic Valve VL-5-1/2-EX - Festo 536034
FESTO Original product
Net price (excl. VAT)
€266.02
Item FES-536034
Manufacturer no. VL-5-1/2-EX
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.VL-5-1/2-EX
EAN4052568170639
Customs tariff number84812090
ConditionNew
Article
FES-536034
Frequently Bought Together
- This Item: €266.02
- Solenoid Valve MFH-3-1/2-S-EX - Festo 535902 €245.95
- Solenoid Valve JMFH-5-1/2-EX - Festo 535914 €350.44
Total price
Festo valve for fast, reliable control of compressed-air direction and flow. The key technical data of this genuine Festo article are listed below.
| Valve function | 5/2 monostable |
| Actuation type | pneumatic |
| Build.width [mm] | 52,0 |
| Normal nominal flow [l/min] | 3.700 |
| Operating pressure [bar] | 0 to 10 |
| Construction set up | Plate seat |
| Reset mode | Mechanical spring |
| Nominal width [mm] | 14 |
| Exhaust function | Can be throttled |
| Sealing principle | Soft |
| installation position | arbitrary |
| Control type | Direct |
| Control air supply | external |
| Flow direction | Not reversible |
| Überdeckung | negative Überdeckung |
| Control pressure [bar] | 1.2 to 10 |
| Shifting time off [ms] | 27 |
| Shifting time on [ms] | 3 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 1 - low corrosion stress |
| Bearing temperature [°C] | -20 to 60 |
| Medium temperature [°C] | -10 to 60 |
| control medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| ambient temperature [°C] | -10 to 60 |
| Product weight [g] | 1.070 |
| Fastening type | With throughway bores<br>Selectively:<br>on terminal strip |
| Pneumatic connection 1 | G1/2 |
| Pneumatic connection 2 | G1/2 |
| Pneumatic connection 3 | G1/2 |
| Material information | RoHs compliant |
| Seals material | NBR<br>TPE-U(PU) |
| Housing material | Aluminium die casting |
| Pitch dimension [mm] | 69 |
| Hand assist actuation | none |
| b-value | 0.32 |
| Pneumatic connection 4 | G1/2 |
| Pneumatic connection 5 | G1/2 |
| C-value [l/sbar] | 17,65 |
| Control air 14 connection | G1/4 |
| CE certificate (see declaration of conformity) | to EU EX protection directive (ATEX) |
| ATEX gas category | II 2G |
| ATEX dust category | II 2D |
| Ex ignition protection type gas | Ex h IIC T4 Gb |
| Ex ignition protection type dust | Ex h IIIC T130°C Db |
| Ex ambient temperature | -10°C <= Ta <= +60°C |
| Breathing opening connection | M3 |
| Manufacturer Nr. | VL-5-1/2-EX |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568170639 |
| Weight | 1.100000 |
| HS-Code | 84812090 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 60 |
| Material | Aluminium |
| Betriebsdruck max [bar] | 10.000000 |
| Pneumatic connection | G1/2 |
| Series | VL |
| Nennweite DN [mm] | 14 |
| Dichtmaterial | NBR, TPE-U(PU) |
| Medium | Compressed air |
| Funktion | 5/2 monostable |
| Durchfluss [l/min] | 3700 |
| Corrosion resistance class CRC | 1 - low corrosion stress |
| Mounting position | arbitrary |
| Design | Plate seat |
| Position sensing | No |
| Actuation type | pneumatic |
