Festo valve for fast, reliable control of compressed-air direction and flow.
Valve VOFD-L50T-M32-MN-FGP14-10-F10 - Festo 4515000
FESTO
Original product
Net price (excl. VAT)
€376.53
Item
FES-4515000
Manufacturer no.
VOFD-L50T-M32-MN-FGP14-10-F10
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.VOFD-L50T-M32-MN-FGP14-10-F10
EAN4052568274894
Customs tariff number84812090
ConditionNew
Article
FES-4515000
Frequently Bought Together
-
This Item:
€376.53
-
Solenoid Valve MHA1-M1H-2/2G-0,9-HC - Festo 197038
€30.76
-
Solenoid Valve MHE3-MS1H-3/2O-1/8-K - Festo 525169
€105.35
Total price
Festo valve for fast, reliable control of compressed-air direction and flow. The key technical data of this genuine Festo article are listed below.
| Valve function | 3/2 closed monostable |
| Actuation type | Electrical |
| Build.width [mm] | 50,5 |
| Normal nominal flow [l/min] | 493 |
| Operating pressure [bar] | 0 to 10 |
| Construction set up | Directly controlled poppet valve |
| Reset mode | Mechanical spring |
| Protection category | IP65 |
| Nominal width [mm] | 5,0 |
| Sealing principle | Soft |
| installation position | arbitrary |
| Hand assist actuation | none |
| Control type | Direct |
| Flow direction | Reversible |
| Vacuum capable | yes |
| b-value | 0.25 |
| C-value [l/sbar] | 2,00 |
| Flow Kv venting [m³/h] | 0,36 |
| Flow Kv venting [m³/h] | 0,36 |
| Normal nominal flow 2-3 [l/min] | 429 |
| Shifting time off [ms] | 60 |
| Shifting time on [ms] | 40 |
| Operating medium | Druckl. ISO8573-1:2010[7:2:2] |
| Corrosion resistant class KBK | 4 - particularly severe corrosion stress |
| Medium temperature [°C] | -25 to 60 |
| ambient temperature [°C] | -25 to 60 |
| Product weight [g] | 560 |
| Pneumatic connection 1 | M5<br>NAMUR wiring diagram |
| Pneumatic connection 2 | NAMUR wiring diagram<br>Flange 1/4 |
| Pneumatic connection 3 | G1/4 |
| Material information | LABS containing materials included<br>RoHs compliant |
| Seals material | NBR |
| Housing material | Aluminium ematal coated |
| Certified awarding point | TÜV V496.02/16 |
| Safety function | Safe venting |
| Safety Integrity Level (SIL) | up to SIL 3 Low Demand mode<br>Product can be used in SRP/CS up to SIL 3 High Demand |
| Expanded ambient temperature | -25 - 60 °C<br>Low demand mode |
| Operating conditions | ISO 8573-1 |
|---|---|
| Manufacturer Nr. | VOFD-L50T-M32-MN-FGP14-10-F10 |
| Manufacturer | Festo |
| EAN | 4052568274894 |
| Weight | 0.650000 |
| HS-Code | 84812090 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 60 |
| Material | Aluminium |
| Betriebsdruck max [bar] | 10.000000 |
| Pneumatic connection | M5 |
| Protection rating | IP65 |
| Series | VOFD |
| Nennweite DN [mm] | 5 |
| Dichtmaterial | NBR |
| Funktion | 3/2 closed monostable |
| Durchfluss [l/min] | 493 |
| Corrosion resistance class CRC | 4 - particularly severe corrosion stress |
| Mounting position | arbitrary |
| Design | Directly controlled poppet valve |
| Position sensing | No |
| Actuation type | Electrical |
