Festo VSVA-B-P53U-ZH-A1-5C1 (547162) Solenoid Valve
€14,913.00
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-547162
Manufacturer Nr.
VSVA-B-P53U-ZH-A1-5C1
Solenoid Valve
Frequently Bought Together
-
This Item:
€14,913.00Excl. 19% VAT , excl. Shipping Cost
-
Festo VSVA-B-B52-H-A2-1C1 (546697) Solenoid Valve
€10,885.00Excl. 19% VAT , excl. Shipping Cost
-
Festo VSVA-B-T32U-AH-A2-2AC1 (547171) Solenoid Valve
€12,845.00Excl. 19% VAT , excl. Shipping Cost
Total price
| Valve function | 5/3 ventilated |
| Actuation type | Electrical |
| Valve size [mm] | 26 |
| Normal nominal flow [l/min] | 1.000 |
| Operating pressure [bar] | -0.9 to 16 |
| Construction set up | Piston pusher |
| Reset mode | Mechanical spring |
| Protection category | IP65 NEMA 4 |
| Nominal width [mm] | 9 |
| Exhaust function | Can be throttled |
| Sealing principle | Soft |
| installation position | arbitrary |
| Complies to standard | ISO 15407-1 VDMA 24563 |
| Hand assist actuation | tentative |
| Control type | pilot operated |
| Control air supply | external |
| Flow direction | Reversible |
| Überdeckung | positive Überdeckung |
| Signal condition display | LED |
| Flow valve [l/min] | 1.400 |
| Flow valve single connection plate [l/min] | 1.100 |
| Flow valve pneumatically linked [l/min] | 1.000 |
| Shifting time off [ms] | 58 |
| Shifting time on [ms] | 23 |
| Power-on time | 100 % |
| Coil characteristic value | 12 V DC: 1,8 W |
| Permitted voltage oscillations | -15 % / +10 % |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Oscillation strength | Transport use test with severity level 2 to FN 942017-4 and EN 60068-2-6 |
| Shock resistance | Shock test with degree of severity 2 to FN 942017-5 and EN 60068-2-27 |
| Corrosion resistant class KBK | 0 - No corrosion stressing |
| Medium temperature [°C] | -5 to 50 |
| Relative humidity | 0 - 90 % |
| Sound level [dB(A)] | 85 |
| control medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| ambient temperature [°C] | -5 to 50 |
| Max. tightening torque Valve fastening [Nm] | 2 |
| Product weight [g] | 305 |
| Electrical connection | Wiring diagram Form C acc. to EN 175301-803 acc. to DIN EN 175301-803 without protective earthing conductor |
| Fastening type | on connection plate |
| Support air control connection 12 | Connection plate Size 26 mm to ISO 15407-1 |
| Support air control connection 14 | Connection plate Size 26 mm to ISO 15407-1 |
| Exhaust control connection 82/84 | Recorded Not recorded to standard |
| Pneumatic connection 1 | Connection plate Size 26 mm to ISO 15407-1 |
| Pneumatic connection 2 | Connection plate Size 26 mm to ISO 15407-1 |
| Pneumatic connection 3 | Connection plate Size 26 mm to ISO 15407-1 |
| Pneumatic connection 4 | Connection plate Size 26 mm to ISO 15407-1 |
| Pneumatic connection 5 | Connection plate Size 26 mm to ISO 15407-1 |
| Pre-control interface | acc. to ISO 15218 |
| Material information | RoHs compliant |
| Seals material | HNBR NBR |
| Housing material | Aluminium die casting |
| Screws material | Steel zinc plating |
| Shifting time um [ms] | 35 |
| Control pressure [bar] | 3 to 10 |
| Manufacturer Nr. | VSVA-B-P53U-ZH-A1-5C1 |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568186784 |
| Weight | 0.320000 |
| HS-Code | 84812090 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
