Festo VUVG-L10-T32H-MT-M5-1R8L (8031470) Solenoid Valve
€9,635.00
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-8031470
Manufacturer Nr.
VUVG-L10-T32H-MT-M5-1R8L
Solenoid Valve
Frequently Bought Together
-
This Item:
€9,635.00Excl. 19% VAT , excl. Shipping Cost
-
Festo VUVG-L14-P53U-T-G18-1R8L (574232) Solenoid Valve
€10,645.00Excl. 19% VAT , excl. Shipping Cost
-
Festo VUVG-L10-T32H-AT-M5-1P3 (566456) Solenoid Valve
€6,834.00Excl. 19% VAT , excl. Shipping Cost
Total price
| Valve function | 2x3/2 open/closed monostable |
| Actuation type | Electrical |
| Valve size [mm] | 10 |
| Normal nominal flow [l/min] | 125 |
| Operating pressure [bar] | 2.5 to 8 |
| Construction set up | Piston pusher |
| Reset mode | Mechanical spring |
| Permission | RCM mark c CSA us (OL) c UL us - Recognized (OL) |
| Protection category | IP65 With Socket |
| Nominal width [mm] | 1,8 |
| Exhaust function | Can be throttled |
| Sealing principle | Soft |
| installation position | arbitrary |
| Hand assist actuation | Ratcheting Covered tentative |
| Control type | pilot operated |
| Control air supply | Internal |
| Überdeckung | positive Überdeckung |
| Control pressure [bar] | 2 to 8 |
| Vacuum capable | no |
| Shifting time off [ms] | 11 |
| Shifting time on [ms] | 8 |
| Power-on time | 100 % |
| Max. positive test impulse at 0 signal [µs] | 700 |
| Max. negative test impulse for 1 signal [µs] | 900 |
| Coil characteristic value | 24 V DC: 1 W |
| Permitted voltage oscillations | ± 10 % |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Oscillation strength | Transport use test with severity level 2 to FN 942017-4 and EN 60068-2-6 |
| Limits ambient and media temperature | -5 - 50 °C Without holding current reduction |
| Shock resistance | Shock test with degree of severity 2 to FN 942017-5 and EN 60068-2-27 |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| Medium temperature [°C] | -5 to 60 |
| ambient temperature [°C] | -5 to 60 |
| Product weight [g] | 54 |
| Electrical connection | Via electrical connection plate |
| Fastening type | With throughway bores Selectively: on terminal strip |
| Pneumatic connection 1 | M5 |
| Pneumatic connection 2 | M5 |
| Pneumatic connection 4 | M5 |
| Pneumatic connection 5 | M5 |
| Material information | RoHs compliant |
| Seals material | HNBR NBR |
| Housing material | Aluminium wrought alloy |
| Manufacturer Nr. | VUVG-L10-T32H-MT-M5-1R8L |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568258757 |
| Weight | 0.060000 |
| HS-Code | 84812090 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
