Festo valve for fast, reliable control of compressed-air direction and flow.
Solenoid Valve CPVSC1-M1H-J-P-Q4 - Festo 527563
FESTO Original product
Net price (excl. VAT)
€164.71
Item FES-527563
Manufacturer no. CPVSC1-M1H-J-P-Q4
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.CPVSC1-M1H-J-P-Q4
EAN4052568162870
Customs tariff number84812090
ConditionNew
Article
FES-527563
Frequently Bought Together
- This Item: €164.71
- Solenoid Valve CPVSC1-M1LH-M-H-Q3 - Festo 547327 €98.95
- Solenoid Valve VMPA14-M1H-DS-PI - Festo 575978 €111.42
Total price
Festo valve for fast, reliable control of compressed-air direction and flow. The key technical data of this genuine Festo article are listed below.
| Valve function | 5/2 bistable |
| Actuation type | Electrical |
| Valve size [mm] | 10 |
| Normal nominal flow [l/min] | 170 |
| Operating pressure [bar] | -0.9 to 7 |
| Construction set up | Piston pusher |
| Protection category | IP40 |
| Exhaust function | Cannot be throttled |
| Sealing principle | Soft |
| installation position | arbitrary |
| Hand assist actuation | Ratcheting<br>tentative |
| Control type | pilot operated |
| Control air supply | external |
| Flow direction | Not reversible |
| Überdeckung | positive Überdeckung |
| Control pressure [bar] | 3 to 7 |
| Max. positive test impulse at 0 signal [µs] | 400 |
| Max. negative test impulse for 1 signal [µs] | 200 |
| Coil characteristic value | 22 V DC: 1 W |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Oscillation strength | Transport use test with severity level 2 to FN 942017-4 and EN 60068-2-6 |
| Shock resistance | Shock test with degree of severity 2 to FN 942017-5 and EN 60068-2-27 |
| Corrosion resistant class KBK | 1 - low corrosion stress |
| ambient temperature [°C] | -5 to 50 |
| Product weight [g] | 56,5 |
| Electrical connection | 2 pin<br>Plug |
| Fastening type | With throughway bores |
| Exhaust control connection 82/84 | Hunt group |
| Pneumatic connection 1 | Hunt group |
| Pneumatic connection 2 | QS-4 |
| Pneumatic connection 3/5 combined | Hunt group |
| Pneumatic connection 4 | QS-4 |
| Material information | RoHs compliant |
| Seals material | NBR |
| Housing material | Aluminium die casting |
| Shifting time um [ms] | 8 |
| Manufacturer Nr. | CPVSC1-M1H-J-P-Q4 |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568162870 |
| Weight | 0.070000 |
| HS-Code | 84812090 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 50 |
| Werkstoff | Aluminium |
| Betriebsdruck max [bar] | 7.000000 |
| Schutzart | IP40 |
| Serie | CPVSC1 |
| Dichtmaterial | NBR |
| Medium | Druckluft |
| Funktion | 5/2 bistabil |
| Durchfluss [l/min] | 170 |
| Corrosion resistance class CRC | 1 - low corrosion stress |
| Mounting position | arbitrary |
| Design | Piston pusher |
| Position sensing | No |
| Actuation type | Electrical |
