Festo pneumatic cylinder for precise linear motion and defined force in automation.
Toothed Belt Axis ELGA-TB-KF-120-800-0H - Festo 8041867
FESTO
Original product
Net price (excl. VAT)
€2,724.88
Item
FES-8041867
Manufacturer no.
ELGA-TB-KF-120-800-0H
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.ELGA-TB-KF-120-800-0H
EAN4052568286675
Customs tariff number84799070
ConditionNew
Article
FES-8041867
Frequently Bought Together
-
This Item:
€2,724.88
-
Spindle Axis ELGA-BS-KF-80-100-0H-20P-ML - Festo 8041829
€1,819.27
-
Toothed Belt Axis ELGA-TB-KF-120-500-0H - Festo 8041865
€2,482.68
Total price
Festo pneumatic cylinder for precise linear motion and defined force in automation. The key technical data of this genuine Festo article are listed below.
| Actuator pinion effective diameter [mm] | 52,52 |
| Working stroke [mm] | 800 |
| size | 120 |
| Stroke reserve [mm] | 0 |
| V-belt bending [%] | 0,210 |
| V-belt separation [mm] | 5 |
| installation position | arbitrary |
| Guide | ball guide |
| Construction set up | Electro-mechanical linear axis<br>With V-belt |
| Motor type | Step motor<br>Servo motor |
| Measurement principle travel measurement system | Incremental |
| Max. acceleration [m/s²] | 50 |
| Max. speed [m/s] | 5 |
| Repeatability | ±0.08 mm |
| Power-on time | 100 % |
| Protection category | IP40 |
| ambient temperature [°C] | -10 to 60 |
| Flat torque 2nd grade ly [mm4] | 1.26458e+006 |
| Flat torque 2nd grade lz [mm4] | 4.36579e+006 |
| Max. actuator torque [Nm] | 34,10 |
| Max. force Fy [N] | 5.500 |
| Max. force Fz [N] | 6.890 |
| Max. empty run shift resistance [N] | 76,2 |
| Max. torque Mx [Nm] | 104 |
| Max. torque My [Nm] | 680 |
| Max. torque Mz [Nm] | 680 |
| Max. feed force Fx [N] | 1.300 |
| Empty run actuator torque [Nm] | 2,8 |
| Torsional moment of inertia to [mm4] | 435.680 |
| Mass inertia JH per metre stroke [kg/cm²] | 2,15 |
| Mass inertia JL per kg usable load [kg/cm²] | 6,90 |
| Mass inertia JO [kg/cm²] | 40,99 |
| Mass inertia JW for additional carriages [kg/cm²] | 28,91 |
| Feed constant [mm/U] | 165 |
| Lubrication interval running section depending [km] | 1.000 |
| Carriage weight [g] | 4.190 |
| Additional carriage weight [g] | 3.240 |
| Weight supplement per 10 mm stroke [g] | 106 |
| Base weight at 0 mm stroke [g] | 15.680 |
| Profile material | Aluminium wrought alloy<br>anodized |
| Material information | LABS containing materials included<br>RoHs compliant |
| Masking tape material | Rust-free stainless steel band |
| Actuator cover material | Aluminium wrought alloy<br>anodized |
| Carriage guide material | Quenched and tempered steel |
| Guide carriage material | Corrotec coated<br>Quenched and tempered steel |
| Belt pulley material | High-alloyed stainless steels |
| Carriage material | Aluminium wrought alloy<br>anodized |
| V-belt clamping body material | Cast stainless steel |
| V-belt material | Polychloroprene with glas cord and nylon covering |
| Manufacturer Nr. | ELGA-TB-KF-120-800-0H |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568286675 |
| Weight | 15.680000 |
| HS-Code | 84799070 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 60 |
| Protection rating | IP40 |
| Series | ELGA |
| Mounting position | arbitrary |
| Design | Electro-mechanical linear axis, With V-belt |
| Position sensing | No |
