Festo ESNU-50-25-P-A (196383) Round Cylinder

Festo
€9,026.00
Excl. 19% VAT , excl. Shipping Cost
Article
FES-196383

Manufacturer Nr.
ESNU-50-25-P-A
Round Cylinder
Add to Wish List Add to Compare
main product photo
The product may differ from the illustration
Frequently Bought Together
Total price
Stroke [mm] 25
Piston diameter 50 mm
Piston rod thread M16x1,5
Dampening P: Elastic silencer rings / plates double-sided
installation position arbitrary
Construction set up Piston
piston rod
cylinder tube
Position detection For proximity switch
Operating pressure [bar] 1.2 to 10
Principle of operation Pressing
single action
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium Oiled operation possible (required in further operations)
Corrosion resistant class KBK 2 - moderate corrosion stress
ambient temperature [°C] -20 to 80
Theoretical force at 6 bar, flow [N] 1.072,8
Moving mass at 0 mm stroke [g] 413,0
Weight supplement per 10 mm stroke [g] 40,0
Base weight at 0 mm stroke [g] 1.087,0
Supplement moved mass per 10 mm stroke [g] 25
Fastening type With Accessories
Pneumatic connection G1/4
Material information RoHs compliant
Cover material Aluminium wrought alloy
Seals material NBR
TPE-U(PU)
Piston rod material High-alloyed steel
Cylinder tube material High-alloyed stainless steels
Spring return force for retracted piston rod [N] 82
Theoretical force at 6 bar, Return flow [N] 82
Moving mass [g] 476
Product weight [g] 1.187
More Information
Manufacturer Nr. ESNU-50-25-P-A
Manufacturer Festo
EAN 4052568159375
Weight 1.200000
HS-Code 84123100
GPSR manufacturer information Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity Original product
Condition of article New
